SDO HMI 2011-01-05 13:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 18.60 | 98.76 | 9.68 | 51.41 | -14.56 | 208.84 | 13.81 | 229.23 | 0.3039 | -107.7 | 91.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-01-05 13:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.53 | 0.00 | 0.81 | -16.33 | 211.98 | 16.95 | 231.25 | 0.3604 | 745.0 | 611.9 | |
| 0.00 | 1.27 | 0.00 | 0.68 | -16.12 | 211.93 | 16.90 | 231.65 | 0.3578 | 814.0 | 621.1 | |
| 3.65 | 26.16 | 1.93 | 13.79 | -15.10 | 211.65 | 16.63 | 233.62 | 0.3446 | 968.4 | 616.2 | |
| 0.00 | 1.10 | 0.00 | 0.58 | -16.40 | 211.44 | 16.42 | 230.23 | 0.3543 | 785.0 | 500.0 | |
| 7.05 | 21.06 | 3.70 | 11.05 | -14.41 | 211.15 | 16.13 | 234.53 | 0.3318 | 1047.9 | 839.9 | |
| 1.36 | -5.00 | 0.71 | -5.00 | -14.42 | 210.86 | 15.84 | 234.06 | 0.3280 | 1066.0 | 999999 | |
| 0.00 | 1.19 | 0.00 | 0.63 | -15.83 | 210.88 | 15.86 | 230.61 | 0.3416 | 771.0 | 622.1 | |
| 0.00 | 2.55 | 0.00 | 1.33 | -14.04 | 210.43 | 15.41 | 234.33 | 0.3187 | 634.0 | 685.0 | |
| 0.00 | 1.70 | 0.00 | 0.89 | -14.55 | 210.18 | 15.16 | 232.57 | 0.3202 | 903.0 | 743.8 | |
| 0.00 | 2.21 | 0.00 | 1.15 | -13.83 | 209.97 | 14.95 | 234.09 | 0.3107 | 873.0 | 729.0 | |
| 0.00 | 1.95 | 0.00 | 1.01 | -13.99 | 207.45 | 12.43 | 228.71 | 0.2792 | -768.0 | -593.5 | |
| 0.00 | 2.97 | 0.00 | 1.53 | -13.73 | 206.72 | 11.70 | 227.78 | 0.2673 | -839.0 | -659.6 | |
| 0.00 | 1.19 | 0.00 | 0.61 | -14.19 | 205.97 | 10.95 | 224.64 | 0.2633 | -916.0 | -751.9 | |
| 0.00 | 2.12 | 0.00 | 1.09 | -14.79 | 205.82 | 10.79 | 222.62 | 0.2687 | -866.0 | -717.9 | |
| 0.00 | 1.70 | 0.00 | 0.87 | -14.46 | 205.61 | 10.59 | 222.96 | 0.2624 | -889.0 | -795.8 | |
| 0.00 | 1.36 | 0.00 | 0.70 | -14.55 | 205.37 | 10.35 | 222.06 | 0.2607 | -828.0 | -684.4 | |
| 0.00 | 3.48 | 0.00 | 1.78 | -14.28 | 205.23 | 10.21 | 222.42 | 0.2559 | -977.0 | -956.0 | |
| 0.00 | 2.38 | 0.00 | 1.22 | -13.78 | 205.09 | 10.07 | 223.43 | 0.2481 | -938.0 | -834.8 | |
| 0.00 | 1.10 | 0.00 | 0.57 | -14.74 | 205.07 | 10.05 | 220.76 | 0.2596 | -718.0 | -588.5 | |
| 0.00 | 1.70 | 0.00 | 0.87 | -14.14 | 204.80 | 9.77 | 221.59 | 0.2491 | -858.0 | -685.8 | |
| 2.80 | 7.81 | 1.43 | 4.00 | -14.41 | 204.75 | 9.72 | 220.71 | 0.2520 | -1096.5 | -724.9 | |
| 3.74 | 3.74 | 1.91 | 1.91 | -13.45 | 204.52 | 9.50 | 222.75 | 0.2376 | -1081.9 | -637.0 | |
| 0.00 | 2.80 | 0.00 | 1.43 | -14.11 | 204.52 | 9.50 | 220.86 | 0.2457 | -899.0 | -886.9 | |
| 0.00 | 2.21 | 0.00 | 1.13 | -13.72 | 204.32 | 9.29 | 221.35 | 0.2386 | -1087.0 | -834.1 | |
| 0.00 | 3.48 | 0.00 | 1.78 | -14.09 | 204.05 | 9.03 | 219.54 | 0.2403 | -1008.0 | -756.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
