SDO HMI 2011-01-09 00:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 45.02 | 259.67 | 33.94 | 195.83 | 31.25 | 185.20 | 35.75 | 318.50 | 0.7561 | -901.4 | -281.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-01-09 00:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.36 | 255.69 | 1.01 | 192.92 | 30.66 | 185.00 | 35.55 | 318.04 | 0.7504 | -947.9 | -277.3 | |
| 43.66 | -1.00 | 32.93 | -1.00 | 31.28 | 185.23 | 35.78 | 318.51 | 0.7566 | -936.2 | 999999 | |
| 0.00 | 1.10 | 0.00 | 0.81 | 30.34 | 184.11 | 34.67 | 318.36 | 0.7412 | -528.0 | -373.4 | |
| 0.00 | 0.93 | 0.00 | 0.68 | 30.50 | 183.59 | 34.15 | 318.91 | 0.7383 | -700.0 | -592.7 | |
| 0.00 | 1.02 | 0.00 | 0.74 | 30.17 | 183.47 | 34.02 | 318.67 | 0.7348 | -595.0 | -582.7 | |
| 0.00 | 0.93 | 0.00 | 0.68 | 30.71 | 183.51 | 34.07 | 319.19 | 0.7393 | -588.0 | -505.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
