SDO HMI 2011-01-11 22:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.59 | 25.14 | 9.16 | 16.97 | 22.95 | 77.11 | -33.94 | 49.14 | 0.6822 | -456.6 | -250.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-01-11 22:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 11.04 | 14.19 | 7.45 | 9.57 | 23.44 | 77.50 | -33.55 | 48.24 | 0.6820 | -834.1 | -695.1 | |
| 0.00 | 1.19 | 0.00 | 0.81 | 23.16 | 76.99 | -34.05 | 48.97 | 0.6848 | -735.0 | -659.9 | |
| 0.51 | 1.61 | 0.35 | 1.10 | 23.44 | 76.64 | -34.40 | 48.90 | 0.6902 | -633.2 | -464.8 | |
| 0.00 | 2.21 | 0.00 | 1.51 | 23.39 | 76.30 | -34.74 | 49.22 | 0.6930 | -689.0 | -627.7 | |
| 2.04 | 3.57 | 1.36 | 2.38 | 21.33 | 76.77 | -34.27 | 51.37 | 0.6738 | 831.5 | 778.4 | |
| 0.00 | 0.93 | 0.00 | 0.63 | 21.51 | 76.53 | -34.51 | 51.34 | 0.6774 | 556.0 | 451.2 | |
| 0.00 | 1.44 | 0.00 | 0.97 | 21.61 | 76.31 | -34.73 | 51.37 | 0.6804 | 340.0 | 272.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
