SDO HMI 2011-02-08 23:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.77 | 48.62 | 11.26 | 30.70 | -20.25 | 64.97 | -36.85 | 114.73 | 0.6215 | 76.8 | -83.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-02-08 23:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.77 | 1.54 | 0.47 | 0.94 | -20.50 | 67.73 | -34.09 | 116.33 | 0.5880 | 905.7 | 777.7 | |
| 5.64 | 7.09 | 3.48 | 4.38 | -20.70 | 66.99 | -34.83 | 116.29 | 0.5982 | 857.8 | 341.6 | |
| 0.00 | 1.11 | 0.00 | 0.69 | -20.94 | 66.93 | -34.90 | 116.65 | 0.6001 | 711.0 | 545.0 | |
| 0.00 | 1.28 | 0.00 | 0.79 | -19.73 | 67.16 | -34.66 | 114.81 | 0.5920 | 854.0 | 598.9 | |
| 0.00 | 1.45 | 0.00 | 0.90 | -20.95 | 66.61 | -35.21 | 116.51 | 0.6040 | 552.0 | 460.9 | |
| 0.00 | 1.54 | 0.00 | 0.95 | -19.43 | 66.82 | -35.01 | 114.17 | 0.5953 | 896.0 | 773.1 | |
| 0.00 | 1.88 | 0.00 | 1.16 | -19.45 | 66.62 | -35.20 | 114.11 | 0.5978 | 695.0 | 537.9 | |
| 1.28 | 3.85 | 0.80 | 2.39 | -20.10 | 66.22 | -35.60 | 114.98 | 0.6054 | 713.5 | 541.3 | |
| 0.00 | 1.03 | 0.00 | 0.64 | -20.95 | 65.68 | -36.15 | 116.08 | 0.6156 | 497.0 | 408.8 | |
| 0.00 | 1.37 | 0.00 | 0.86 | -21.07 | 65.53 | -36.30 | 116.19 | 0.6179 | 593.0 | 542.9 | |
| 0.00 | 1.62 | 0.00 | 1.02 | -19.70 | 64.76 | -37.06 | 113.74 | 0.6222 | -837.0 | -674.3 | |
| 1.62 | 6.75 | 1.03 | 4.29 | -20.23 | 64.54 | -37.29 | 114.48 | 0.6269 | -887.7 | -686.2 | |
| 1.62 | 2.56 | 1.03 | 1.63 | -20.09 | 64.26 | -37.57 | 114.15 | 0.6298 | -725.3 | -482.6 | |
| 0.00 | 1.11 | 0.00 | 0.71 | -20.32 | 63.55 | -38.27 | 114.23 | 0.6393 | -734.0 | -640.8 | |
| 0.00 | 4.53 | 0.00 | 2.90 | -19.73 | 63.52 | -38.31 | 113.33 | 0.6377 | -629.0 | -553.6 | |
| 0.00 | 1.79 | 0.00 | 1.17 | -20.45 | 62.78 | -39.04 | 114.14 | 0.6491 | -810.0 | -693.0 | |
| 3.16 | 3.33 | 2.05 | 2.16 | -20.17 | 62.74 | -39.08 | 113.71 | 0.6486 | -805.8 | -481.5 | |
| 3.68 | 4.79 | 2.40 | 3.12 | -20.40 | 62.47 | -39.35 | 113.95 | 0.6527 | -656.1 | -491.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
