SDO HMI 2011-02-09 21:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 29.23 | 67.63 | 16.32 | 37.75 | -20.35 | 65.43 | -24.33 | 122.93 | 0.4610 | -40.9 | -13.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-02-09 21:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.67 | 14.79 | 3.63 | 8.05 | -20.44 | 68.98 | -20.77 | 126.59 | 0.4157 | 1085.4 | 831.2 | |
| 0.00 | 1.20 | 0.00 | 0.65 | -20.13 | 68.22 | -21.54 | 125.08 | 0.4231 | 940.0 | 792.2 | |
| 0.00 | 1.03 | 0.00 | 0.56 | -20.40 | 68.14 | -21.62 | 125.55 | 0.4262 | 718.0 | 527.4 | |
| 1.54 | 1.88 | 0.84 | 1.03 | -19.95 | 68.11 | -21.65 | 124.57 | 0.4230 | 802.2 | 642.8 | |
| 4.53 | 9.23 | 2.48 | 5.06 | -20.30 | 67.92 | -21.84 | 125.10 | 0.4283 | 964.5 | 598.1 | |
| 0.00 | 1.20 | 0.00 | 0.66 | -20.55 | 67.17 | -22.59 | 124.78 | 0.4398 | 683.0 | 450.0 | |
| 0.00 | 0.77 | 0.00 | 0.43 | -20.64 | 66.36 | -23.40 | 124.14 | 0.4508 | 503.0 | 329.6 | |
| 0.00 | 1.20 | 0.00 | 0.67 | -22.28 | 66.04 | -23.71 | 126.94 | 0.4675 | 642.0 | 493.6 | |
| 0.00 | 1.11 | 0.00 | 0.62 | -20.65 | 64.56 | -25.20 | 122.46 | 0.4742 | -927.0 | -777.9 | |
| 0.00 | 3.08 | 0.00 | 1.73 | -19.99 | 64.32 | -25.44 | 121.01 | 0.4729 | -855.0 | -783.9 | |
| 0.00 | 1.20 | 0.00 | 0.68 | -20.21 | 63.69 | -26.07 | 120.90 | 0.4826 | -856.0 | -733.7 | |
| 0.00 | 2.39 | 0.00 | 1.35 | -19.84 | 63.58 | -26.18 | 120.10 | 0.4817 | -791.0 | -719.5 | |
| 5.04 | 5.81 | 2.85 | 3.29 | -20.23 | 63.44 | -26.32 | 120.73 | 0.4860 | -940.9 | -704.3 | |
| 1.28 | 1.80 | 0.73 | 1.02 | -20.30 | 63.18 | -26.58 | 120.67 | 0.4899 | -784.9 | -816.7 | |
| 3.59 | 16.41 | 2.04 | 9.35 | -20.29 | 62.90 | -26.86 | 120.42 | 0.4935 | -977.9 | -714.5 | |
| 6.58 | -15.00 | 3.75 | -15.00 | -20.49 | 62.68 | -27.07 | 120.63 | 0.4975 | -786.7 | 999999 | |
| 0.00 | 3.59 | 0.00 | 2.05 | -20.32 | 62.25 | -27.50 | 119.99 | 0.5020 | -623.0 | -521.5 | |
| 0.00 | 0.94 | 0.00 | 0.55 | -19.80 | 60.46 | -29.30 | 117.79 | 0.5226 | 642.0 | 489.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
