SDO HMI 2011-02-10 04:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 8.90 | 36.29 | 5.21 | 21.42 | 19.54 | 65.63 | -20.30 | 36.86 | 0.5456 | -163.3 | -98.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-02-10 04:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.37 | 2.14 | 0.79 | 1.24 | 19.34 | 68.18 | -17.75 | 33.64 | 0.5212 | -884.6 | -702.3 | |
| 1.97 | 10.10 | 1.14 | 5.86 | 19.16 | 67.80 | -18.12 | 34.40 | 0.5221 | -1056.7 | -767.7 | |
| 0.00 | 0.94 | 0.00 | 0.54 | 18.58 | 67.47 | -18.45 | 35.55 | 0.5180 | -748.0 | -676.6 | |
| 0.00 | 2.14 | 0.00 | 1.25 | 19.48 | 67.14 | -18.79 | 34.99 | 0.5315 | -669.0 | -611.9 | |
| 3.59 | 4.88 | 2.10 | 2.86 | 19.69 | 66.91 | -19.01 | 35.08 | 0.5359 | -673.7 | -646.8 | |
| 0.00 | 1.03 | 0.00 | 0.60 | 19.34 | 66.46 | -19.47 | 36.11 | 0.5357 | -740.0 | -560.2 | |
| 0.00 | 1.11 | 0.00 | 0.65 | 19.45 | 66.28 | -19.65 | 36.23 | 0.5385 | -738.0 | -616.5 | |
| 0.00 | 1.03 | 0.00 | 0.62 | 20.91 | 64.53 | -21.40 | 36.87 | 0.5702 | 727.0 | 519.1 | |
| 0.00 | 1.20 | 0.00 | 0.72 | 20.61 | 64.54 | -21.39 | 37.20 | 0.5668 | 857.0 | 702.3 | |
| 1.97 | 6.50 | 1.18 | 3.91 | 19.65 | 63.15 | -22.78 | 40.05 | 0.5688 | 899.3 | 641.9 | |
| 0.00 | 4.02 | 0.00 | 2.42 | 19.35 | 62.51 | -23.41 | 41.18 | 0.5716 | 839.0 | 756.5 | |
| 0.00 | 1.20 | 0.00 | 0.75 | 21.10 | 59.35 | -26.57 | 42.62 | 0.6186 | 572.0 | 387.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
