SDO HMI 2011-02-11 17:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.63 | 43.97 | 7.48 | 22.48 | -20.39 | 68.23 | 2.60 | 189.91 | 0.2504 | 106.1 | 67.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-02-11 17:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.22 | 9.67 | 2.67 | 4.95 | -20.14 | 71.52 | 5.89 | 202.40 | 0.2541 | 1039.1 | 886.3 | |
| 0.00 | 1.45 | 0.00 | 0.75 | -20.50 | 71.53 | 5.90 | 201.87 | 0.2598 | 753.0 | 450.2 | |
| 0.00 | 1.37 | 0.00 | 0.70 | -21.17 | 71.46 | 5.84 | 200.66 | 0.2699 | 882.0 | 709.7 | |
| 6.33 | 7.87 | 3.24 | 4.02 | -20.08 | 71.07 | 5.45 | 200.95 | 0.2504 | 1099.0 | 806.8 | |
| 0.00 | 1.97 | 0.00 | 1.01 | -20.54 | 70.71 | 5.08 | 199.02 | 0.2556 | 926.0 | 725.9 | |
| 0.00 | 2.65 | 0.00 | 1.36 | -20.33 | 70.61 | 4.98 | 198.96 | 0.2517 | 880.0 | 796.5 | |
| 0.00 | 0.94 | 0.00 | 0.48 | -20.43 | 69.47 | 3.84 | 194.76 | 0.2477 | 837.0 | 709.8 | |
| 0.00 | 1.03 | 0.00 | 0.52 | -20.43 | 69.25 | 3.62 | 193.94 | 0.2468 | 917.0 | 662.2 | |
| 0.00 | 1.37 | 0.00 | 0.70 | -20.29 | 66.03 | 0.40 | 181.60 | 0.2371 | -562.0 | -440.3 | |
| 0.00 | 1.03 | 0.00 | 0.52 | -20.78 | 64.89 | -0.74 | 177.18 | 0.2456 | -858.0 | -661.6 | |
| 0.00 | 1.80 | 0.00 | 0.92 | -20.57 | 64.83 | -0.80 | 176.90 | 0.2420 | -800.0 | -573.6 | |
| 0.00 | 1.45 | 0.00 | 0.74 | -20.72 | 64.64 | -0.99 | 176.20 | 0.2448 | -954.0 | -792.9 | |
| 0.00 | 0.94 | 0.00 | 0.48 | -21.15 | 64.61 | -1.02 | 176.19 | 0.2520 | -630.0 | -581.5 | |
| 0.00 | 0.94 | 0.00 | 0.48 | -20.87 | 64.54 | -1.08 | 175.88 | 0.2475 | -949.0 | -827.1 | |
| 3.08 | 3.85 | 1.57 | 1.96 | -19.99 | 64.17 | -1.46 | 174.09 | 0.2330 | -1073.0 | -860.0 | |
| 0.00 | 2.65 | 0.00 | 1.35 | -20.50 | 63.16 | -2.47 | 170.43 | 0.2440 | -1083.0 | -886.4 | |
| 0.00 | 1.11 | 0.00 | 0.57 | -20.94 | 60.52 | -5.11 | 161.40 | 0.2621 | -860.0 | -704.2 | |
| 0.00 | 1.88 | 0.00 | 0.97 | -21.37 | 60.47 | -5.16 | 161.79 | 0.2691 | -765.0 | -612.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
