SDO HMI 2011-02-11 20:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 45.09 | 117.45 | 25.65 | 67.40 | -19.60 | 35.86 | -28.11 | 118.18 | 0.5048 | 122.9 | -46.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-02-11 20:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 19.42 | 41.66 | 10.81 | 23.20 | -19.33 | 39.20 | -24.78 | 120.10 | 0.4591 | 1033.7 | 537.2 | |
| 2.91 | -1.00 | 1.62 | -1.00 | -19.05 | 39.03 | -24.94 | 119.41 | 0.4595 | 881.0 | 999999 | |
| 1.37 | 1.54 | 0.77 | 0.87 | -18.70 | 37.56 | -26.41 | 117.57 | 0.4773 | 837.4 | 706.0 | |
| 3.25 | 5.47 | 1.84 | 3.10 | -18.85 | 36.94 | -27.03 | 117.42 | 0.4865 | 853.8 | 499.8 | |
| 0.00 | 2.22 | 0.00 | 1.26 | -18.74 | 36.57 | -27.40 | 116.95 | 0.4909 | 675.0 | 530.2 | |
| 0.00 | 0.86 | 0.00 | 0.49 | -18.64 | 36.31 | -27.66 | 116.57 | 0.4939 | 469.0 | 448.2 | |
| 0.00 | 1.03 | 0.00 | 0.59 | -19.53 | 35.40 | -28.58 | 117.64 | 0.5109 | -711.0 | -687.1 | |
| 0.00 | 1.37 | 0.00 | 0.79 | -18.09 | 35.17 | -28.81 | 114.81 | 0.5067 | 839.0 | 668.3 | |
| 11.12 | 27.37 | 6.44 | 15.86 | -19.30 | 34.51 | -29.46 | 116.65 | 0.5215 | -995.9 | -621.2 | |
| 0.00 | 2.14 | 0.00 | 1.25 | -20.63 | 34.16 | -29.81 | 118.79 | 0.5330 | 1015.0 | 830.1 | |
| 0.00 | 3.76 | 0.00 | 2.19 | -19.81 | 34.30 | -29.67 | 117.43 | 0.5269 | -769.0 | -607.8 | |
| 2.14 | -9.00 | 1.24 | -9.00 | -18.84 | 34.46 | -29.52 | 115.78 | 0.5199 | -920.9 | 999999 | |
| 0.00 | 0.94 | 0.00 | 0.55 | -19.59 | 34.23 | -29.74 | 117.00 | 0.5266 | -567.0 | -394.5 | |
| 0.00 | 0.94 | 0.00 | 0.55 | -20.38 | 34.07 | -29.90 | 118.29 | 0.5329 | 711.0 | 549.5 | |
| 0.00 | 0.94 | 0.00 | 0.55 | -21.01 | 33.89 | -30.08 | 119.28 | 0.5386 | 786.0 | 625.6 | |
| 0.00 | 1.54 | 0.00 | 0.90 | -20.58 | 33.95 | -30.02 | 118.58 | 0.5355 | 843.0 | 677.2 | |
| 0.00 | 1.28 | 0.00 | 0.75 | -18.86 | 34.17 | -29.81 | 115.63 | 0.5239 | -721.0 | -631.3 | |
| 0.60 | 2.48 | 0.35 | 1.46 | -20.75 | 33.62 | -30.35 | 118.66 | 0.5406 | 787.0 | 713.1 | |
| 0.00 | 1.54 | 0.00 | 0.90 | -18.87 | 33.94 | -30.03 | 115.54 | 0.5269 | -827.0 | -684.4 | |
| 0.00 | 7.01 | 0.00 | 4.09 | -19.10 | 33.72 | -30.26 | 115.82 | 0.5310 | -670.0 | -612.0 | |
| 0.00 | 1.63 | 0.00 | 0.96 | -20.46 | 32.84 | -31.13 | 117.68 | 0.5492 | 639.0 | 486.9 | |
| 4.28 | 6.59 | 2.58 | 3.98 | -21.76 | 31.41 | -32.57 | 119.02 | 0.5740 | -927.3 | -620.1 | |
| 0.00 | 2.74 | 0.00 | 1.66 | -22.06 | 31.22 | -32.76 | 119.40 | 0.5778 | -814.0 | -658.8 | |
| 0.00 | 0.77 | 0.00 | 0.46 | -20.93 | 31.50 | -32.47 | 117.71 | 0.5687 | -845.0 | -642.6 | |
| 0.00 | 1.63 | 0.00 | 0.99 | -22.26 | 30.97 | -33.00 | 119.58 | 0.5819 | -618.0 | -508.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
