SDO HMI 2011-02-12 02:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 55.04 | 153.38 | 30.63 | 85.61 | -19.72 | 35.98 | -24.70 | 121.08 | 0.4601 | 131.1 | 31.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-02-12 02:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.54 | 55.12 | 11.16 | 29.94 | -19.32 | 39.37 | -21.31 | 123.41 | 0.4125 | 1086.7 | 498.5 | |
| 0.00 | 2.05 | 0.00 | 1.12 | -19.22 | 38.48 | -22.20 | 122.25 | 0.4237 | 876.0 | 645.7 | |
| 5.22 | 8.13 | 2.87 | 4.47 | -18.91 | 37.57 | -23.11 | 120.71 | 0.4337 | 991.5 | 692.0 | |
| 0.00 | 1.03 | 0.00 | 0.57 | -18.98 | 37.19 | -23.50 | 120.50 | 0.4394 | 725.0 | 512.6 | |
| 2.40 | 3.42 | 1.32 | 1.89 | -18.82 | 36.87 | -23.81 | 119.87 | 0.4426 | 782.6 | 698.3 | |
| 0.00 | 0.86 | 0.00 | 0.47 | -18.21 | 36.14 | -24.54 | 117.99 | 0.4487 | -589.0 | -540.8 | |
| 0.00 | 1.54 | 0.00 | 0.86 | -19.52 | 35.03 | -25.65 | 119.72 | 0.4718 | -952.0 | -775.1 | |
| 0.00 | 1.37 | 0.00 | 0.76 | -18.16 | 35.22 | -25.46 | 117.17 | 0.4611 | 712.0 | 588.1 | |
| 0.00 | 4.54 | 0.00 | 2.57 | -20.52 | 34.25 | -26.43 | 121.01 | 0.4883 | 792.0 | 745.0 | |
| 14.21 | 38.26 | 8.00 | 21.55 | -19.19 | 34.42 | -26.26 | 118.60 | 0.4779 | -1094.2 | -684.3 | |
| 2.05 | -10.00 | 1.16 | -10.00 | -18.85 | 34.38 | -26.30 | 117.90 | 0.4765 | -1006.2 | 999999 | |
| 1.37 | -10.00 | 0.77 | -10.00 | -19.42 | 34.14 | -26.54 | 118.82 | 0.4830 | -566.1 | 999999 | |
| 0.00 | 1.11 | 0.00 | 0.64 | -21.84 | 33.64 | -27.04 | 122.92 | 0.5048 | 790.0 | 627.2 | |
| 3.94 | 4.96 | 2.24 | 2.83 | -20.69 | 33.83 | -26.85 | 120.97 | 0.4948 | 749.7 | 517.4 | |
| 0.00 | 4.28 | 0.00 | 2.45 | -21.32 | 33.57 | -27.11 | 121.92 | 0.5022 | 680.0 | 622.2 | |
| 0.00 | 1.80 | 0.00 | 1.02 | -19.10 | 33.95 | -26.73 | 118.08 | 0.4838 | -619.0 | -482.7 | |
| 0.00 | 1.54 | 0.00 | 0.88 | -20.43 | 33.63 | -27.05 | 120.35 | 0.4958 | 578.0 | 307.9 | |
| 0.00 | 3.00 | 0.00 | 1.69 | -18.89 | 33.88 | -26.80 | 117.61 | 0.4834 | -834.0 | -631.4 | |
| 0.00 | 0.94 | 0.00 | 0.53 | -19.06 | 33.64 | -27.04 | 117.76 | 0.4876 | -664.0 | -463.2 | |
| 0.00 | 1.97 | 0.00 | 1.13 | -20.50 | 33.16 | -27.52 | 120.11 | 0.5024 | 839.0 | 635.9 | |
| 0.00 | 1.28 | 0.00 | 0.74 | -21.40 | 32.18 | -28.50 | 121.01 | 0.5204 | -743.0 | -606.8 | |
| 1.63 | 2.40 | 0.95 | 1.41 | -22.43 | 31.26 | -29.42 | 122.13 | 0.5383 | -835.4 | -725.2 | |
| 3.68 | 13.78 | 2.16 | 8.09 | -21.99 | 31.14 | -29.54 | 121.30 | 0.5371 | -1053.0 | -717.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
