SDO HMI 2011-02-12 13:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 21.91 | 38.09 | 12.84 | 22.41 | 19.25 | 34.55 | -20.12 | 36.99 | 0.5417 | -573.8 | -89.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-02-12 13:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 18.23 | 22.00 | 10.69 | 12.90 | 19.42 | 35.21 | -19.46 | 35.91 | 0.5378 | -907.3 | -606.9 | |
| 1.37 | 3.25 | 0.80 | 1.90 | 18.93 | 35.14 | -19.53 | 36.58 | 0.5328 | -755.0 | -675.7 | |
| 0.94 | -2.00 | 0.55 | -2.00 | 18.80 | 35.09 | -19.58 | 36.80 | 0.5317 | -836.7 | 999999 | |
| 1.37 | 3.17 | 0.80 | 1.86 | 18.92 | 34.61 | -20.06 | 37.32 | 0.5373 | -649.6 | -500.2 | |
| 0.00 | 0.94 | 0.00 | 0.56 | 19.75 | 33.73 | -20.94 | 37.52 | 0.5545 | -581.0 | -454.4 | |
| 0.00 | 2.31 | 0.00 | 1.36 | 18.47 | 33.63 | -21.04 | 39.18 | 0.5412 | 833.0 | 562.1 | |
| 0.00 | 1.11 | 0.00 | 0.66 | 19.44 | 33.26 | -21.40 | 38.49 | 0.5552 | -463.0 | -383.8 | |
| 0.00 | 0.94 | 0.00 | 0.56 | 19.21 | 33.26 | -21.41 | 38.76 | 0.5526 | -741.0 | -564.5 | |
| 0.00 | 2.91 | 0.00 | 1.72 | 18.57 | 32.88 | -21.79 | 40.03 | 0.5492 | 754.0 | 575.9 | |
| 0.00 | 1.46 | 0.00 | 0.89 | 20.23 | 30.58 | -24.09 | 40.83 | 0.5880 | 670.0 | 509.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
