SDO HMI 2011-02-12 23:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 16.34 | 46.14 | 9.31 | 26.34 | 19.28 | 34.41 | -14.75 | 28.86 | 0.4993 | -278.3 | -192.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-02-12 23:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.35 | 20.29 | 7.60 | 11.55 | 19.54 | 35.43 | -13.73 | 26.97 | 0.4951 | -959.1 | -566.7 | |
| 0.00 | 1.37 | 0.00 | 0.78 | 19.11 | 35.37 | -13.79 | 27.49 | 0.4898 | -879.0 | -668.1 | |
| 1.71 | 12.33 | 0.97 | 7.00 | 19.09 | 34.92 | -14.24 | 28.27 | 0.4927 | -609.8 | -529.2 | |
| 0.00 | 2.05 | 0.00 | 1.17 | 18.91 | 33.61 | -15.55 | 30.61 | 0.5000 | -584.0 | -431.6 | |
| 0.00 | 1.54 | 0.00 | 0.88 | 18.51 | 33.58 | -15.57 | 31.08 | 0.4952 | 876.0 | 710.5 | |
| 1.28 | 1.63 | 0.74 | 0.94 | 18.92 | 32.24 | -16.92 | 32.74 | 0.5110 | -478.6 | -540.8 | |
| 0.00 | 1.28 | 0.00 | 0.74 | 18.61 | 31.88 | -17.28 | 33.65 | 0.5101 | 835.0 | 655.2 | |
| 0.00 | 1.03 | 0.00 | 0.59 | 19.01 | 31.64 | -17.52 | 33.55 | 0.5170 | 800.0 | 629.6 | |
| 0.00 | 2.05 | 0.00 | 1.19 | 19.18 | 31.49 | -17.67 | 33.58 | 0.5203 | 891.0 | 681.7 | |
| 0.00 | 1.03 | 0.00 | 0.60 | 19.26 | 31.18 | -17.97 | 33.95 | 0.5237 | 692.0 | 599.6 | |
| 0.00 | 1.54 | 0.00 | 0.90 | 20.17 | 30.65 | -18.51 | 33.71 | 0.5391 | 787.0 | 687.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
