SDO HMI 2011-02-14 15:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 342.41 | 1718.92 | 175.95 | 883.59 | -20.19 | 34.52 | 7.29 | 206.85 | 0.2694 | -162.7 | 9.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-02-14 15:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.46 | 0.00 | 0.76 | -18.94 | 41.02 | 13.79 | 226.53 | 0.3121 | 622.0 | 421.9 | |
| 4.88 | 394.56 | 2.53 | 203.83 | -18.26 | 40.26 | 13.03 | 226.68 | 0.2956 | 994.6 | 464.5 | |
| 0.69 | -2.00 | 0.35 | -2.00 | -17.87 | 40.23 | 13.00 | 227.65 | 0.2911 | 810.1 | 999999 | |
| 33.57 | -2.00 | 17.34 | -2.00 | -18.10 | 39.55 | 12.32 | 225.57 | 0.2853 | 1466.6 | 999999 | |
| 8.48 | -2.00 | 4.38 | -2.00 | -18.60 | 39.14 | 11.91 | 223.36 | 0.2861 | 1183.4 | 999999 | |
| 0.00 | 0.94 | 0.00 | 0.49 | -21.02 | 39.32 | 12.09 | 218.21 | 0.3175 | -551.0 | -482.7 | |
| 0.69 | -2.00 | 0.35 | -2.00 | -18.02 | 38.97 | 11.74 | 224.45 | 0.2776 | 1045.1 | 999999 | |
| 6.17 | -2.00 | 3.19 | -2.00 | -19.08 | 39.01 | 11.78 | 221.87 | 0.2905 | 1083.3 | 999999 | |
| 4.28 | -2.00 | 2.22 | -2.00 | -19.30 | 38.71 | 11.48 | 220.62 | 0.2898 | 945.1 | 999999 | |
| 0.00 | 2.14 | 0.00 | 1.12 | -21.88 | 38.19 | 10.96 | 213.93 | 0.3176 | 843.0 | 657.3 | |
| 2.14 | 7.02 | 1.10 | 3.60 | -18.73 | 36.89 | 9.66 | 217.29 | 0.2634 | -825.0 | -336.1 | |
| 0.00 | 1.28 | 0.00 | 0.66 | -18.04 | 36.72 | 9.49 | 218.56 | 0.2527 | -823.0 | -658.1 | |
| 3.85 | 672.29 | 1.99 | 344.68 | -20.56 | 36.81 | 9.58 | 213.03 | 0.2871 | 810.2 | -29.4 | |
| 1.28 | -13.00 | 0.66 | -13.00 | -19.50 | 36.65 | 9.42 | 214.85 | 0.2712 | -594.1 | 999999 | |
| 3.60 | 11.82 | 1.84 | 6.05 | -18.23 | 36.51 | 9.28 | 217.48 | 0.2529 | -1054.1 | -827.6 | |
| 0.00 | 1.28 | 0.00 | 0.66 | -19.22 | 36.54 | 9.31 | 215.15 | 0.2664 | -993.0 | -819.6 | |
| 0.00 | 1.54 | 0.00 | 0.79 | -18.80 | 36.45 | 9.22 | 215.88 | 0.2599 | -632.0 | -629.7 | |
| 0.00 | 2.57 | 0.00 | 1.32 | -18.65 | 36.31 | 9.08 | 215.85 | 0.2566 | -1044.0 | -862.9 | |
| 42.14 | -13.00 | 21.68 | -13.00 | -19.96 | 36.01 | 8.78 | 212.02 | 0.2716 | 1300.5 | 999999 | |
| 2.31 | -13.00 | 1.19 | -13.00 | -20.48 | 35.97 | 8.74 | 210.88 | 0.2786 | 868.3 | 999999 | |
| 0.00 | 6.42 | 0.00 | 3.29 | -18.90 | 35.85 | 8.62 | 213.89 | 0.2556 | -122.0 | -88.7 | |
| 2.57 | -13.00 | 1.31 | -13.00 | -18.45 | 35.61 | 8.38 | 214.19 | 0.2471 | 850.5 | 999999 | |
| 0.00 | 1.20 | 0.00 | 0.62 | -20.70 | 35.34 | 8.11 | 208.65 | 0.2766 | 746.0 | 651.1 | |
| 1.37 | -13.00 | 0.70 | -13.00 | -20.31 | 35.26 | 8.03 | 209.14 | 0.2702 | 586.7 | 999999 | |
| 6.85 | -13.00 | 3.52 | -13.00 | -20.04 | 35.21 | 7.98 | 209.54 | 0.2659 | 911.2 | 999999 | |
| 0.00 | 1.20 | 0.00 | 0.62 | -21.13 | 35.21 | 7.98 | 207.48 | 0.2818 | 747.0 | 535.4 | |
| 0.00 | 0.94 | 0.00 | 0.49 | -21.14 | 35.05 | 7.82 | 207.01 | 0.2806 | 835.0 | 629.8 | |
| 1.54 | -13.00 | 0.79 | -13.00 | -20.44 | 34.79 | 7.56 | 207.48 | 0.2684 | 503.4 | 999999 | |
| 7.37 | -13.00 | 3.78 | -13.00 | -20.23 | 34.71 | 7.48 | 207.64 | 0.2647 | 951.0 | 999999 | |
| 3.08 | 6.94 | 1.59 | 3.58 | -21.33 | 34.67 | 7.44 | 205.59 | 0.2807 | 1005.9 | 742.5 | |
| 27.06 | -13.00 | 13.86 | -13.00 | -19.71 | 34.56 | 7.33 | 208.14 | 0.2559 | -1247.1 | 999999 | |
| 0.00 | 6.68 | 0.00 | 3.45 | -21.70 | 34.47 | 7.24 | 204.39 | 0.2848 | 636.0 | 576.5 | |
| 8.48 | -13.00 | 4.33 | -13.00 | -19.17 | 34.10 | 6.87 | 207.68 | 0.2442 | -1016.3 | 999999 | |
| 1.54 | 6.17 | 0.79 | 3.17 | -21.03 | 34.18 | 6.95 | 204.59 | 0.2727 | 491.0 | 804.8 | |
| 5.57 | -13.00 | 2.85 | -13.00 | -19.93 | 33.94 | 6.71 | 205.70 | 0.2544 | -766.2 | 999999 | |
| 0.60 | -13.00 | 0.31 | -13.00 | -20.39 | 33.96 | 6.73 | 204.96 | 0.2615 | 1081.1 | 999999 | |
| 0.00 | 6.68 | 0.00 | 3.44 | -21.52 | 34.01 | 6.78 | 203.29 | 0.2790 | 805.0 | 630.8 | |
| 1.37 | -13.00 | 0.70 | -13.00 | -20.24 | 33.92 | 6.69 | 205.10 | 0.2589 | 900.2 | 999999 | |
| 22.87 | -13.00 | 11.67 | -13.00 | -19.33 | 33.54 | 6.30 | 205.44 | 0.2424 | -1432.8 | 999999 | |
| 4.28 | -13.00 | 2.20 | -13.00 | -20.67 | 33.53 | 6.30 | 203.09 | 0.2628 | 1126.4 | 999999 | |
| 0.00 | 3.00 | 0.00 | 1.54 | -21.31 | 33.52 | 6.29 | 202.09 | 0.2726 | 783.0 | 634.7 | |
| 0.69 | -13.00 | 0.35 | -13.00 | -18.91 | 33.39 | 6.16 | 205.74 | 0.2349 | -1150.1 | 999999 | |
| 0.00 | 4.45 | 0.00 | 2.29 | -21.53 | 33.37 | 6.14 | 201.31 | 0.2750 | 29.0 | 352.6 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -19.82 | 33.02 | 5.79 | 202.75 | 0.2464 | -577.0 | -460.8 | |
| 2.74 | -13.00 | 1.40 | -13.00 | -20.46 | 32.91 | 5.68 | 201.38 | 0.2557 | 985.0 | 999999 | |
| 0.00 | 2.74 | 0.00 | 1.41 | -22.21 | 32.98 | 5.75 | 199.20 | 0.2834 | -507.0 | -618.8 | |
| 0.00 | 1.37 | 0.00 | 0.70 | -20.01 | 32.90 | 5.67 | 202.03 | 0.2485 | 865.0 | 577.2 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -21.44 | 32.82 | 5.59 | 199.69 | 0.2705 | 544.0 | 335.0 | |
| 0.00 | 2.14 | 0.00 | 1.10 | -22.40 | 32.06 | 4.83 | 196.10 | 0.2818 | -552.0 | -442.2 | |
| 1.37 | 563.87 | 0.71 | 289.70 | -22.22 | 31.89 | 4.66 | 195.77 | 0.2781 | -890.7 | -304.2 | |
| 0.00 | 2.31 | 0.00 | 1.19 | -21.21 | 31.70 | 4.47 | 196.24 | 0.2610 | -826.0 | -714.9 | |
| 0.00 | 1.37 | 0.00 | 0.70 | -19.60 | 31.37 | 4.14 | 197.03 | 0.2333 | -682.0 | -605.2 | |
| 8.91 | -50.00 | 4.59 | -50.00 | -22.38 | 31.32 | 4.09 | 193.77 | 0.2782 | -1083.1 | 999999 | |
| 3.51 | -50.00 | 1.79 | -50.00 | -20.11 | 31.16 | 3.93 | 195.59 | 0.2407 | 1006.5 | 999999 | |
| 4.28 | -50.00 | 2.20 | -50.00 | -22.16 | 31.12 | 3.89 | 193.32 | 0.2740 | -1127.2 | 999999 | |
| 12.16 | -50.00 | 6.29 | -50.00 | -22.96 | 31.08 | 3.85 | 192.50 | 0.2869 | -1038.5 | 999999 | |
| 1.03 | -50.00 | 0.52 | -50.00 | -20.33 | 30.91 | 3.68 | 194.42 | 0.2432 | 566.0 | 999999 | |
| 4.80 | -50.00 | 2.45 | -50.00 | -20.67 | 30.86 | 3.63 | 193.86 | 0.2484 | -986.0 | 999999 | |
| 2.83 | -50.00 | 1.45 | -50.00 | -22.20 | 30.74 | 3.51 | 192.02 | 0.2731 | -859.8 | 999999 | |
| 2.57 | -50.00 | 1.31 | -50.00 | -20.67 | 30.54 | 3.31 | 192.69 | 0.2472 | -761.5 | 999999 | |
| 15.33 | -50.00 | 7.92 | -50.00 | -23.03 | 30.57 | 3.34 | 190.83 | 0.2862 | -1053.2 | 999999 | |
| 70.91 | -50.00 | 36.39 | -50.00 | -21.65 | 30.37 | 3.14 | 191.23 | 0.2628 | -1360.4 | 999999 | |
| 2.65 | -50.00 | 1.36 | -50.00 | -21.10 | 30.27 | 3.04 | 191.30 | 0.2534 | -1048.8 | 999999 | |
| 0.00 | 1.54 | 0.00 | 0.80 | -23.06 | 29.70 | 2.47 | 188.04 | 0.2845 | -789.0 | -529.6 | |
| 0.00 | 0.94 | 0.00 | 0.48 | -22.39 | 28.82 | 1.59 | 185.45 | 0.2715 | 659.0 | 471.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
