SDO HMI 2011-02-15 10:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 27.26 | 77.94 | 23.16 | 66.01 | 19.77 | 64.72 | 47.90 | 300.56 | 0.8121 | 201.0 | 195.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-02-15 10:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.60 | 0.00 | 0.54 | 17.92 | 68.72 | 51.91 | 296.62 | 0.8398 | 309.0 | 241.6 | |
| 8.74 | 17.06 | 8.04 | 15.75 | 19.06 | 68.80 | 51.99 | 297.85 | 0.8444 | -701.8 | -65.4 | |
| 0.00 | 2.23 | 0.00 | 2.07 | 19.50 | 69.00 | 52.19 | 298.25 | 0.8476 | 190.0 | 156.0 | |
| 0.00 | 1.80 | 0.00 | 1.59 | 18.88 | 67.27 | 50.46 | 298.30 | 0.8309 | -452.0 | -414.5 | |
| 0.00 | 1.80 | 0.00 | 1.60 | 19.11 | 67.32 | 50.50 | 298.54 | 0.8322 | -518.0 | -426.4 | |
| 0.00 | 2.57 | 0.00 | 2.25 | 18.55 | 66.94 | 50.13 | 298.08 | 0.8269 | -219.0 | -375.7 | |
| 0.00 | 0.69 | 0.00 | 0.58 | 20.29 | 64.24 | 47.43 | 301.28 | 0.8105 | 346.0 | 279.9 | |
| 0.00 | 3.09 | 0.00 | 2.57 | 20.22 | 63.84 | 47.03 | 301.41 | 0.8067 | 338.0 | 261.8 | |
| 0.00 | 0.86 | 0.00 | 0.71 | 20.20 | 63.65 | 46.83 | 301.48 | 0.8049 | 334.0 | 292.1 | |
| 2.14 | 4.20 | 1.77 | 3.47 | 20.01 | 63.39 | 46.58 | 301.40 | 0.8018 | 549.7 | 502.6 | |
| 7.29 | 36.35 | 5.92 | 29.53 | 19.85 | 62.69 | 45.87 | 301.58 | 0.7948 | 831.5 | 414.8 | |
| 1.29 | 2.14 | 1.08 | 1.81 | 21.91 | 63.51 | 46.70 | 303.45 | 0.8115 | -428.3 | -385.8 | |
| 7.80 | -11.00 | 6.35 | -11.00 | 20.23 | 62.56 | 45.75 | 302.08 | 0.7954 | 764.7 | 999999 | |
| 0.00 | 0.43 | 0.00 | 0.34 | 21.82 | 61.05 | 44.24 | 304.68 | 0.7899 | 535.0 | 504.8 | |
| 0.00 | 2.49 | 0.00 | 1.94 | 20.64 | 60.04 | 43.23 | 303.92 | 0.7747 | 615.0 | 487.4 | |
| 0.00 | 1.63 | 0.00 | 1.26 | 20.71 | 59.67 | 42.86 | 304.21 | 0.7717 | 741.0 | 571.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
