SDO HMI 2011-03-03 05:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 241.58 | 1324.51 | 141.86 | 777.23 | 24.74 | 164.35 | -4.47 | 7.53 | 0.5381 | 164.5 | 168.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-03-03 05:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.42 | 330.14 | 1.43 | 194.09 | 25.77 | 169.49 | 0.67 | 358.89 | 0.5471 | -867.8 | -387.0 | |
| 1.64 | -1.00 | 0.97 | -1.00 | 25.98 | 169.49 | 0.68 | 358.89 | 0.5502 | -499.7 | 999999 | |
| 2.50 | -1.00 | 1.46 | -1.00 | 24.75 | 169.39 | 0.57 | 359.02 | 0.5319 | -1305.8 | 999999 | |
| 40.76 | -1.00 | 23.99 | -1.00 | 25.45 | 169.32 | 0.51 | 359.15 | 0.5423 | -1125.1 | 999999 | |
| 7.86 | -1.00 | 4.60 | -1.00 | 25.03 | 169.16 | 0.34 | 359.42 | 0.5361 | -1282.3 | 999999 | |
| 3.45 | -1.00 | 2.02 | -1.00 | 24.78 | 169.03 | 0.21 | 359.64 | 0.5324 | -1318.5 | 999999 | |
| 0.86 | -1.00 | 0.51 | -1.00 | 25.59 | 168.80 | -0.02 | 0.03 | 0.5444 | -878.9 | 999999 | |
| 1.21 | -1.00 | 0.71 | -1.00 | 24.68 | 168.70 | -0.12 | 0.20 | 0.5308 | -871.4 | 999999 | |
| 2.94 | -1.00 | 1.71 | -1.00 | 24.43 | 168.60 | -0.21 | 0.37 | 0.5272 | -886.2 | 999999 | |
| 0.00 | 4.66 | 0.00 | 2.71 | 24.12 | 168.44 | -0.38 | 0.66 | 0.5225 | -890.0 | -669.9 | |
| 0.00 | 1.38 | 0.00 | 0.80 | 24.22 | 168.01 | -0.80 | 1.40 | 0.5242 | 318.0 | 176.6 | |
| 0.00 | 0.69 | 0.00 | 0.40 | 23.84 | 167.79 | -1.03 | 1.82 | 0.5186 | -756.0 | -614.4 | |
| 0.00 | 2.16 | 0.00 | 1.25 | 24.15 | 167.07 | -1.75 | 3.05 | 0.5238 | -566.0 | -526.2 | |
| 0.00 | 1.21 | 0.00 | 0.72 | 26.45 | 167.00 | -1.81 | 2.92 | 0.5576 | -563.0 | -405.4 | |
| 0.00 | 2.76 | 0.00 | 1.59 | 23.43 | 166.95 | -1.87 | 3.35 | 0.5129 | -887.0 | -731.3 | |
| 0.00 | 2.16 | 0.00 | 1.25 | 23.77 | 166.88 | -1.94 | 3.43 | 0.5182 | -852.0 | -706.8 | |
| 0.00 | 1.12 | 0.00 | 0.65 | 23.60 | 166.85 | -1.97 | 3.51 | 0.5156 | -735.0 | -648.6 | |
| 1.21 | 3.80 | 0.70 | 2.21 | 24.36 | 166.81 | -2.01 | 3.49 | 0.5271 | -537.0 | -333.4 | |
| 1.30 | 11.05 | 0.75 | 6.41 | 24.05 | 166.61 | -2.20 | 3.86 | 0.5226 | -864.3 | -519.5 | |
| 2.33 | -19.00 | 1.35 | -19.00 | 24.16 | 166.45 | -2.37 | 4.13 | 0.5244 | -453.1 | 999999 | |
| 0.00 | 5.87 | 0.00 | 3.40 | 23.71 | 165.71 | -3.10 | 5.51 | 0.5186 | 424.0 | 370.6 | |
| 0.00 | 1.04 | 0.00 | 0.61 | 24.62 | 165.36 | -3.45 | 5.93 | 0.5326 | -439.0 | -360.8 | |
| 0.00 | 1.38 | 0.00 | 0.78 | 21.79 | 165.27 | -3.54 | 6.74 | 0.4905 | -759.0 | -540.6 | |
| 0.00 | 1.38 | 0.00 | 0.79 | 21.99 | 165.20 | -3.61 | 6.82 | 0.4937 | -701.0 | -503.6 | |
| 2.68 | 760.36 | 1.55 | 441.85 | 23.65 | 164.93 | -3.88 | 6.89 | 0.5189 | 800.2 | 479.0 | |
| 1.21 | -25.00 | 0.70 | -25.00 | 24.06 | 164.92 | -3.90 | 6.81 | 0.5252 | -111.6 | 999999 | |
| 15.46 | -25.00 | 9.01 | -25.00 | 24.38 | 164.88 | -3.94 | 6.81 | 0.5299 | -612.1 | 999999 | |
| 5.96 | -25.00 | 3.47 | -25.00 | 24.14 | 164.66 | -4.16 | 7.25 | 0.5267 | 271.6 | 999999 | |
| 3.11 | -25.00 | 1.79 | -25.00 | 23.20 | 164.62 | -4.19 | 7.56 | 0.5129 | 973.1 | 999999 | |
| 2.25 | -25.00 | 1.29 | -25.00 | 22.79 | 164.50 | -4.31 | 7.89 | 0.5070 | 1069.8 | 999999 | |
| 1.47 | -25.00 | 0.85 | -25.00 | 23.06 | 164.43 | -4.38 | 7.94 | 0.5112 | 1058.4 | 999999 | |
| 1.30 | 2.59 | 0.73 | 1.47 | 21.36 | 164.42 | -4.39 | 8.49 | 0.4856 | -814.7 | -719.9 | |
| 1.99 | 5.18 | 1.14 | 2.96 | 22.48 | 164.32 | -4.49 | 8.31 | 0.5028 | 966.9 | 756.9 | |
| 1.21 | -25.00 | 0.71 | -25.00 | 24.60 | 164.12 | -4.70 | 8.04 | 0.5345 | 634.2 | 999999 | |
| 0.00 | 1.64 | 0.00 | 0.93 | 21.22 | 164.17 | -4.65 | 9.01 | 0.4842 | -625.0 | -547.9 | |
| 0.00 | 1.04 | 0.00 | 0.59 | 22.28 | 164.10 | -4.71 | 8.78 | 0.5002 | 894.0 | 752.8 | |
| 0.00 | 1.38 | 0.00 | 0.82 | 25.69 | 163.97 | -4.84 | 7.97 | 0.5507 | 228.0 | 274.1 | |
| 0.00 | 1.81 | 0.00 | 1.03 | 21.56 | 164.09 | -4.72 | 9.03 | 0.4895 | -741.0 | -598.1 | |
| 0.00 | 0.86 | 0.00 | 0.52 | 26.30 | 163.92 | -4.90 | 7.90 | 0.5596 | 567.0 | 473.5 | |
| 0.00 | 1.90 | 0.00 | 1.08 | 21.90 | 164.05 | -4.77 | 9.00 | 0.4947 | -484.0 | -352.8 | |
| 0.00 | 1.81 | 0.00 | 1.08 | 25.98 | 163.86 | -4.95 | 8.07 | 0.5551 | 687.0 | 539.3 | |
| 0.26 | -25.00 | 0.15 | -25.00 | 23.52 | 163.93 | -4.89 | 8.69 | 0.5191 | 1033.7 | 999999 | |
| 0.00 | 1.55 | 0.00 | 0.92 | 25.80 | 163.80 | -5.01 | 8.21 | 0.5526 | 772.0 | 615.9 | |
| 0.00 | 3.11 | 0.00 | 1.88 | 27.23 | 163.64 | -5.18 | 8.07 | 0.5735 | 655.0 | 503.2 | |
| 6.74 | -25.00 | 3.90 | -25.00 | 23.56 | 163.73 | -5.08 | 9.02 | 0.5201 | 1136.8 | 999999 | |
| 0.00 | 0.78 | 0.00 | 0.46 | 25.62 | 163.65 | -5.17 | 8.52 | 0.5504 | 581.0 | 449.8 | |
| 0.00 | 1.12 | 0.00 | 0.64 | 21.54 | 163.26 | -5.55 | 10.60 | 0.4913 | -584.0 | -421.1 | |
| 0.00 | 3.80 | 0.00 | 2.30 | 27.36 | 162.62 | -6.19 | 9.58 | 0.5774 | 653.0 | 519.7 | |
| 94.56 | -25.00 | 55.09 | -25.00 | 23.95 | 162.67 | -6.15 | 10.71 | 0.5286 | 1288.1 | 999999 | |
| 1.73 | -25.00 | 1.00 | -25.00 | 23.37 | 162.50 | -6.31 | 11.23 | 0.5205 | 1198.9 | 999999 | |
| 2.07 | -25.00 | 1.19 | -25.00 | 22.27 | 162.39 | -6.42 | 11.89 | 0.5047 | 1093.5 | 999999 | |
| 5.18 | 6.91 | 3.14 | 4.19 | 27.37 | 161.75 | -7.07 | 10.90 | 0.5798 | 779.9 | 456.9 | |
| 3.20 | 6.74 | 1.92 | 4.05 | 26.47 | 161.60 | -7.21 | 11.46 | 0.5677 | 870.8 | 664.9 | |
| 0.00 | 1.04 | 0.00 | 0.63 | 27.34 | 161.45 | -7.37 | 11.37 | 0.5802 | 781.0 | 619.5 | |
| 0.00 | 0.86 | 0.00 | 0.53 | 27.60 | 161.29 | -7.52 | 11.50 | 0.5842 | 538.0 | 430.6 | |
| 0.00 | 0.69 | 0.00 | 0.41 | 26.19 | 161.29 | -7.53 | 12.06 | 0.5646 | 785.0 | 714.2 | |
| 0.00 | 1.04 | 0.00 | 0.62 | 25.98 | 161.17 | -7.65 | 12.34 | 0.5620 | 731.0 | 563.3 | |
| 0.00 | 1.47 | 0.00 | 0.88 | 26.20 | 161.12 | -7.70 | 12.32 | 0.5652 | 727.0 | 634.5 | |
| 0.00 | 5.09 | 0.00 | 3.09 | 27.21 | 160.88 | -7.93 | 12.27 | 0.5800 | 668.0 | 605.8 | |
| 0.00 | 1.04 | 0.00 | 0.63 | 27.14 | 160.62 | -8.20 | 12.69 | 0.5799 | 529.0 | 497.9 | |
| 0.00 | 1.04 | 0.00 | 0.63 | 26.64 | 160.55 | -8.26 | 13.00 | 0.5731 | 874.0 | 748.8 | |
| 0.00 | 3.28 | 0.00 | 1.97 | 26.00 | 160.33 | -8.48 | 13.63 | 0.5650 | 944.0 | 676.0 | |
| 0.00 | 1.12 | 0.00 | 0.68 | 26.32 | 160.31 | -8.51 | 13.52 | 0.5695 | 613.0 | 484.4 | |
| 0.00 | 1.30 | 0.00 | 0.77 | 25.82 | 160.31 | -8.50 | 13.74 | 0.5626 | 875.0 | 685.1 | |
| 0.00 | 1.47 | 0.00 | 0.84 | 22.20 | 160.45 | -8.36 | 15.36 | 0.5105 | 703.0 | 613.4 | |
| 0.00 | 1.81 | 0.00 | 1.07 | 24.62 | 160.23 | -8.59 | 14.45 | 0.5460 | 941.0 | 746.2 | |
| 0.00 | 0.78 | 0.00 | 0.45 | 21.96 | 160.37 | -8.45 | 15.64 | 0.5074 | 910.0 | 698.6 | |
| 1.55 | 79.36 | 0.96 | 49.02 | 28.61 | 159.85 | -8.96 | 13.17 | 0.6024 | -350.8 | -223.8 | |
| 15.72 | -68.00 | 9.69 | -68.00 | 28.21 | 159.72 | -9.10 | 13.54 | 0.5974 | -1051.9 | 999999 | |
| 0.00 | 2.59 | 0.00 | 1.60 | 28.11 | 159.11 | -9.71 | 14.45 | 0.5982 | -780.0 | -712.7 | |
| 0.00 | 1.12 | 0.00 | 0.69 | 28.16 | 158.69 | -10.12 | 15.02 | 0.6003 | -677.0 | -574.4 | |
| 0.00 | 1.90 | 0.00 | 1.10 | 22.23 | 159.18 | -9.63 | 17.53 | 0.5163 | 680.0 | 537.6 | |
| 0.00 | 0.95 | 0.00 | 0.58 | 27.62 | 158.68 | -10.14 | 15.31 | 0.5930 | -631.0 | -512.6 | |
| 0.00 | 0.78 | 0.00 | 0.45 | 21.48 | 159.14 | -9.68 | 18.09 | 0.5058 | 468.0 | 422.6 | |
| 0.00 | 1.73 | 0.00 | 1.03 | 25.15 | 158.79 | -10.02 | 16.44 | 0.5589 | 745.0 | 517.5 | |
| 0.00 | 1.90 | 0.00 | 1.12 | 24.45 | 158.79 | -10.03 | 16.85 | 0.5492 | 732.0 | 586.5 | |
| 1.73 | 6.13 | 1.07 | 3.80 | 28.17 | 158.32 | -10.50 | 15.54 | 0.6018 | -781.0 | -571.4 | |
| 0.00 | 1.90 | 0.00 | 1.17 | 27.55 | 158.34 | -10.47 | 15.82 | 0.5934 | -730.0 | -585.1 | |
| 0.00 | 1.21 | 0.00 | 0.75 | 28.47 | 158.22 | -10.60 | 15.53 | 0.6061 | -603.0 | -406.2 | |
| 1.73 | 6.82 | 1.08 | 4.25 | 28.69 | 158.06 | -10.76 | 15.64 | 0.6096 | -559.3 | 12.6 | |
| 0.00 | 0.86 | 0.00 | 0.53 | 27.89 | 157.97 | -10.85 | 16.18 | 0.5993 | -600.0 | -407.0 | |
| 0.00 | 1.21 | 0.00 | 0.77 | 30.56 | 157.57 | -11.25 | 15.37 | 0.6359 | -663.0 | -518.6 | |
| 0.00 | 0.78 | 0.00 | 0.49 | 29.40 | 157.53 | -11.29 | 16.00 | 0.6210 | -328.0 | -310.6 | |
| 1.99 | 3.89 | 1.23 | 2.41 | 28.26 | 157.62 | -11.20 | 16.47 | 0.6057 | -724.4 | -595.4 | |
| 0.00 | 1.38 | 0.00 | 0.85 | 27.75 | 157.67 | -11.14 | 16.66 | 0.5987 | -666.0 | -493.9 | |
| 0.00 | 2.76 | 0.00 | 1.64 | 24.71 | 157.93 | -10.88 | 18.02 | 0.5566 | 612.0 | 606.7 | |
| 0.00 | 1.81 | 0.00 | 1.08 | 24.65 | 157.74 | -11.08 | 18.36 | 0.5565 | 661.0 | 476.2 | |
| 0.00 | 0.95 | 0.00 | 0.58 | 27.47 | 157.26 | -11.56 | 17.40 | 0.5967 | -602.0 | -443.5 | |
| 0.00 | 0.86 | 0.00 | 0.52 | 25.71 | 157.34 | -11.48 | 18.31 | 0.5729 | 698.0 | 578.8 | |
| 0.00 | 1.47 | 0.00 | 0.87 | 23.96 | 157.47 | -11.35 | 19.22 | 0.5484 | 750.0 | 611.6 | |
| 0.00 | 1.64 | 0.00 | 0.99 | 25.97 | 157.21 | -11.61 | 18.35 | 0.5768 | 556.0 | 416.2 | |
| 0.00 | 1.12 | 0.00 | 0.67 | 24.65 | 156.30 | -12.51 | 20.54 | 0.5635 | 665.0 | 549.8 | |
| 0.00 | 1.04 | 0.00 | 0.68 | 30.86 | 154.01 | -14.80 | 19.67 | 0.6539 | -653.0 | -534.2 | |
| 0.00 | 1.21 | 0.00 | 0.78 | 29.83 | 153.68 | -15.14 | 20.72 | 0.6427 | -822.0 | -678.7 | |
| 0.00 | 1.73 | 0.00 | 1.18 | 33.55 | 152.29 | -16.52 | 20.06 | 0.6932 | -602.0 | -490.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
