SDO HMI 2011-03-04 02:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 9.75 | 0.00 | 11.42 | 24.55 | 215.41 | 58.12 | 301.48 | 0.9072 | 51.7 | -88.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-03-04 02:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 4.23 | 0.00 | 5.13 | 24.52 | 216.51 | 59.22 | 301.05 | 0.9141 | -566.0 | -309.8 | |
| 0.00 | 1.55 | 0.00 | 1.87 | 24.76 | 216.17 | 58.89 | 301.41 | 0.9127 | -370.0 | -297.2 | |
| 0.00 | 0.78 | 0.00 | 0.84 | 23.38 | 213.31 | 56.03 | 301.06 | 0.8905 | 302.0 | 288.0 | |
| 0.00 | 1.38 | 0.00 | 1.60 | 25.58 | 214.67 | 57.39 | 302.80 | 0.9057 | 46.0 | 130.6 | |
| 0.00 | 1.12 | 0.00 | 1.23 | 24.24 | 213.41 | 56.13 | 301.91 | 0.8938 | 367.0 | 277.1 | |
| 0.00 | 0.69 | 0.00 | 0.75 | 23.84 | 213.14 | 55.86 | 301.60 | 0.8908 | 531.0 | 465.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
