SDO HMI 2011-03-05 18:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.74 | 38.86 | 4.98 | 28.46 | -22.44 | 182.12 | 46.79 | 246.05 | 0.7394 | 69.3 | 247.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-03-05 18:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.33 | 0.00 | 1.74 | -20.53 | 183.39 | 48.06 | 248.89 | 0.7491 | 574.0 | 455.7 | |
| 2.25 | 27.55 | 1.66 | 20.32 | -21.97 | 182.67 | 47.34 | 246.84 | 0.7442 | 703.9 | 544.4 | |
| 4.49 | -2.00 | 3.32 | -2.00 | -22.31 | 182.64 | 47.31 | 246.37 | 0.7445 | 794.8 | 999999 | |
| 0.00 | 1.12 | 0.00 | 0.82 | -23.02 | 182.10 | 46.77 | 245.30 | 0.7405 | -173.0 | -140.5 | |
| 0.00 | 1.30 | 0.00 | 0.93 | -23.74 | 180.37 | 45.04 | 243.87 | 0.7238 | -404.0 | -357.7 | |
| 0.00 | 0.60 | 0.00 | 0.43 | -23.66 | 180.15 | 44.82 | 243.91 | 0.7212 | -720.0 | -597.1 | |
| 0.00 | 2.59 | 0.00 | 1.85 | -24.24 | 179.99 | 44.66 | 243.07 | 0.7212 | -757.0 | -607.3 | |
| 0.00 | 2.16 | 0.00 | 1.52 | -23.51 | 179.35 | 44.02 | 243.87 | 0.7121 | -777.0 | -677.1 | |
| 0.00 | 1.21 | 0.00 | 0.85 | -23.76 | 179.41 | 44.08 | 243.56 | 0.7135 | -720.0 | -565.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
