SDO HMI 2011-03-07 13:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 203.92 | 1210.42 | 200.99 | 1194.56 | 23.52 | 164.51 | 52.77 | 302.61 | 0.8673 | 43.0 | -27.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-03-07 13:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.86 | 0.00 | 1.01 | 22.46 | 170.59 | 58.85 | 299.04 | 0.9065 | -205.0 | -159.1 | |
| 0.00 | 2.59 | 0.00 | 2.76 | 20.91 | 168.34 | 56.60 | 298.24 | 0.8871 | -532.0 | -488.1 | |
| 6.49 | 457.14 | 7.11 | 468.33 | 21.96 | 168.86 | 57.12 | 299.15 | 0.8937 | -576.9 | -345.7 | |
| 2.08 | -3.00 | 2.27 | -3.00 | 22.38 | 168.64 | 56.90 | 299.66 | 0.8934 | -372.5 | 999999 | |
| 2.59 | -3.00 | 2.76 | -3.00 | 22.08 | 167.82 | 56.08 | 299.67 | 0.8869 | -673.5 | 999999 | |
| 1.73 | -3.00 | 1.80 | -3.00 | 21.76 | 167.28 | 55.54 | 299.54 | 0.8821 | -633.6 | 999999 | |
| 2.68 | 144.54 | 3.12 | 165.68 | 25.28 | 169.45 | 57.71 | 302.37 | 0.9068 | 330.3 | -89.4 | |
| 12.20 | -3.00 | 12.81 | -3.00 | 22.32 | 167.27 | 55.53 | 300.14 | 0.8838 | -617.9 | 999999 | |
| 0.00 | 0.69 | 0.00 | 0.89 | 27.89 | 171.29 | 59.55 | 304.34 | 0.9244 | 80.0 | 88.1 | |
| 23.09 | -7.00 | 26.32 | -7.00 | 25.08 | 168.87 | 57.13 | 302.38 | 0.9026 | -836.0 | 999999 | |
| 3.11 | -3.00 | 3.22 | -3.00 | 22.42 | 166.65 | 54.91 | 300.49 | 0.8797 | -851.8 | 999999 | |
| 1.21 | 1.47 | 1.29 | 1.57 | 23.57 | 167.24 | 55.50 | 301.45 | 0.8874 | -177.5 | -206.7 | |
| 1.47 | 1.82 | 1.54 | 1.90 | 23.05 | 166.86 | 55.12 | 301.06 | 0.8832 | -199.8 | -256.2 | |
| 8.22 | -3.00 | 8.45 | -3.00 | 22.76 | 166.34 | 54.60 | 300.97 | 0.8786 | -742.0 | 999999 | |
| 0.00 | 0.95 | 0.00 | 0.99 | 23.18 | 166.48 | 54.75 | 301.35 | 0.8810 | -560.0 | -501.5 | |
| 0.00 | 1.12 | 0.00 | 1.10 | 21.18 | 165.29 | 53.55 | 299.72 | 0.8657 | 63.0 | 106.5 | |
| 14.27 | -3.00 | 15.12 | -3.00 | 24.00 | 166.82 | 55.09 | 302.06 | 0.8859 | -688.1 | 999999 | |
| 0.00 | 1.21 | 0.00 | 1.18 | 20.95 | 165.01 | 53.27 | 299.59 | 0.8628 | 354.0 | 329.9 | |
| 5.80 | -3.00 | 5.64 | -3.00 | 22.19 | 164.49 | 52.75 | 301.14 | 0.8632 | -707.3 | 999999 | |
| 4.84 | -3.00 | 4.75 | -3.00 | 22.73 | 164.52 | 52.78 | 301.70 | 0.8653 | 490.4 | 999999 | |
| 0.00 | 1.82 | 0.00 | 1.72 | 21.48 | 163.80 | 52.06 | 300.68 | 0.8554 | -549.0 | -447.0 | |
| 2.59 | -3.00 | 2.59 | -3.00 | 23.40 | 164.79 | 53.05 | 302.29 | 0.8697 | 440.6 | 999999 | |
| 0.00 | 2.42 | 0.00 | 2.33 | 22.74 | 163.67 | 51.94 | 302.08 | 0.8590 | -414.0 | -297.2 | |
| 0.00 | 2.85 | 0.00 | 3.07 | 26.63 | 166.02 | 54.28 | 305.12 | 0.8892 | 312.0 | 289.8 | |
| 7.09 | 54.93 | 6.51 | 51.07 | 21.06 | 162.61 | 50.87 | 300.75 | 0.8445 | 547.6 | -145.9 | |
| 3.72 | 6.05 | 3.52 | 5.73 | 22.42 | 163.19 | 51.45 | 301.96 | 0.8542 | 215.6 | 87.7 | |
| 2.16 | -25.00 | 1.99 | -25.00 | 21.52 | 162.58 | 50.84 | 301.26 | 0.8460 | 462.5 | 999999 | |
| 0.00 | 1.30 | 0.00 | 1.20 | 21.74 | 162.43 | 50.70 | 301.57 | 0.8457 | 318.0 | 244.4 | |
| 0.00 | 1.73 | 0.00 | 1.72 | 24.79 | 164.04 | 52.30 | 304.07 | 0.8693 | -235.0 | -174.0 | |
| 0.00 | 1.12 | 0.00 | 1.09 | 23.79 | 163.30 | 51.56 | 303.35 | 0.8602 | 378.0 | 300.7 | |
| 0.00 | 0.78 | 0.00 | 0.66 | 18.48 | 160.52 | 48.78 | 298.86 | 0.8168 | 483.0 | 430.3 | |
| 0.00 | 12.80 | 0.00 | 12.67 | 25.06 | 163.67 | 51.93 | 304.52 | 0.8676 | 251.0 | 139.3 | |
| 0.00 | 2.25 | 0.00 | 2.16 | 24.00 | 163.05 | 51.31 | 303.69 | 0.8591 | 480.0 | 356.8 | |
| 0.86 | 214.43 | 0.79 | 190.23 | 22.18 | 161.79 | 50.05 | 302.33 | 0.8423 | 86.3 | 444.8 | |
| 2.16 | 10.99 | 2.06 | 10.55 | 24.20 | 162.64 | 50.90 | 304.09 | 0.8568 | 530.5 | 139.9 | |
| 7.44 | -34.00 | 6.71 | -34.00 | 22.06 | 161.33 | 49.59 | 302.43 | 0.8382 | 593.8 | 999999 | |
| 0.00 | 7.87 | 0.00 | 7.74 | 25.52 | 163.15 | 51.41 | 305.24 | 0.8657 | 235.0 | 165.1 | |
| 0.86 | 1.90 | 0.86 | 1.89 | 26.13 | 163.30 | 51.57 | 305.80 | 0.8691 | -172.4 | -65.6 | |
| 4.15 | -34.00 | 3.75 | -34.00 | 22.35 | 161.17 | 49.43 | 302.81 | 0.8381 | 557.2 | 999999 | |
| 7.87 | 194.45 | 7.45 | 179.48 | 24.42 | 162.20 | 50.46 | 304.54 | 0.8544 | 518.2 | 314.5 | |
| 0.00 | 0.86 | 0.00 | 0.80 | 23.37 | 161.53 | 49.79 | 303.73 | 0.8451 | 374.0 | 304.0 | |
| 2.85 | -34.00 | 2.57 | -34.00 | 22.60 | 160.94 | 49.21 | 303.19 | 0.8373 | 418.6 | 999999 | |
| 0.00 | 0.69 | 0.00 | 0.62 | 22.83 | 160.91 | 49.17 | 303.45 | 0.8380 | 285.0 | 211.8 | |
| 0.00 | 0.95 | 0.00 | 0.87 | 23.33 | 161.16 | 49.42 | 303.87 | 0.8421 | 382.0 | 337.1 | |
| 8.56 | -34.00 | 7.57 | -34.00 | 21.97 | 160.40 | 48.66 | 302.77 | 0.8303 | 839.5 | 999999 | |
| 15.48 | -34.00 | 13.73 | -34.00 | 22.43 | 160.32 | 48.59 | 303.31 | 0.8317 | 933.7 | 999999 | |
| 1.38 | -34.00 | 1.24 | -34.00 | 22.92 | 160.51 | 48.77 | 303.75 | 0.8353 | 759.9 | 999999 | |
| 34.86 | -40.00 | 32.12 | -40.00 | 24.53 | 160.93 | 49.19 | 305.26 | 0.8454 | 871.5 | 999999 | |
| 0.00 | 3.98 | 0.00 | 3.59 | 23.67 | 160.48 | 48.75 | 304.56 | 0.8383 | 672.0 | 668.3 | |
| 2.08 | -34.00 | 1.83 | -34.00 | 22.79 | 159.81 | 48.07 | 303.95 | 0.8291 | 713.2 | 999999 | |
| 1.21 | 64.79 | 1.16 | 62.08 | 27.06 | 161.09 | 49.35 | 307.81 | 0.8573 | -239.5 | 165.9 | |
| 0.35 | -51.00 | 0.33 | -51.00 | 27.03 | 160.87 | 49.13 | 307.90 | 0.8557 | -504.2 | 999999 | |
| 2.85 | -51.00 | 2.72 | -51.00 | 27.27 | 160.80 | 49.07 | 308.18 | 0.8563 | -352.1 | 999999 | |
| 0.78 | -51.00 | 0.74 | -51.00 | 27.49 | 160.89 | 49.15 | 308.36 | 0.8578 | 240.4 | 999999 | |
| 0.00 | 1.12 | 0.00 | 0.97 | 23.05 | 158.40 | 46.66 | 304.97 | 0.8188 | 530.0 | 461.4 | |
| 4.84 | -51.00 | 4.55 | -51.00 | 27.08 | 160.28 | 48.54 | 308.24 | 0.8517 | -668.6 | 999999 | |
| 0.00 | 0.95 | 0.00 | 0.81 | 23.28 | 157.94 | 46.20 | 305.46 | 0.8161 | 675.0 | 595.5 | |
| 0.00 | 0.78 | 0.00 | 0.67 | 23.52 | 158.00 | 46.26 | 305.69 | 0.8178 | 452.0 | 429.1 | |
| 0.00 | 2.59 | 0.00 | 2.24 | 24.14 | 158.00 | 46.26 | 306.35 | 0.8208 | 648.0 | 499.1 | |
| 0.00 | 0.86 | 0.00 | 0.75 | 25.72 | 157.20 | 45.47 | 308.46 | 0.8224 | 484.0 | 428.2 | |
| 0.00 | 0.78 | 0.00 | 0.69 | 27.11 | 157.72 | 45.99 | 309.62 | 0.8332 | 394.0 | 352.2 | |
| 0.00 | 0.69 | 0.00 | 0.61 | 27.04 | 157.45 | 45.71 | 309.70 | 0.8309 | 433.0 | 413.2 | |
| 0.00 | 1.30 | 0.00 | 1.14 | 30.50 | 154.69 | 42.95 | 314.80 | 0.8296 | -494.0 | -383.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
