SDO HMI 2011-03-08 00:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 154.35 | 948.92 | 181.31 | 1113.84 | 23.78 | 164.33 | 58.65 | 300.55 | 0.9079 | 36.3 | -22.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-03-08 00:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.62 | 34.35 | 7.73 | 47.34 | 21.89 | 169.40 | 63.72 | 296.88 | 0.9344 | -389.8 | -145.0 | |
| 0.00 | 0.95 | 0.00 | 1.32 | 22.33 | 169.47 | 63.80 | 297.31 | 0.9356 | -36.0 | -59.9 | |
| 0.61 | 372.55 | 0.80 | 444.89 | 22.37 | 168.14 | 62.46 | 297.76 | 0.9283 | -281.3 | -288.9 | |
| 1.90 | -3.00 | 2.47 | -3.00 | 22.33 | 167.76 | 62.08 | 297.84 | 0.9260 | -368.9 | 999999 | |
| 0.00 | 1.04 | 0.00 | 1.30 | 21.41 | 167.00 | 61.32 | 297.13 | 0.9195 | -570.0 | -534.5 | |
| 2.86 | -3.00 | 3.63 | -3.00 | 22.43 | 167.22 | 61.54 | 298.12 | 0.9230 | -398.5 | 999999 | |
| 4.50 | 119.31 | 6.43 | 168.49 | 25.20 | 169.24 | 63.56 | 300.29 | 0.9398 | 201.7 | -79.6 | |
| 1.21 | -3.00 | 1.52 | -3.00 | 22.55 | 166.84 | 61.16 | 298.37 | 0.9211 | -591.4 | 999999 | |
| 0.35 | -3.00 | 0.44 | -3.00 | 22.69 | 166.88 | 61.20 | 298.50 | 0.9216 | -386.2 | 999999 | |
| 16.35 | -7.00 | 22.83 | -7.00 | 25.03 | 168.64 | 62.96 | 300.31 | 0.9364 | -585.7 | 999999 | |
| 0.00 | 0.78 | 0.00 | 0.99 | 23.06 | 166.89 | 61.22 | 298.87 | 0.9225 | -178.0 | -143.7 | |
| 6.83 | -3.00 | 8.51 | -3.00 | 22.68 | 166.46 | 60.79 | 298.62 | 0.9191 | -552.8 | 999999 | |
| 0.00 | 1.64 | 0.00 | 2.09 | 23.27 | 166.92 | 61.24 | 299.07 | 0.9231 | -284.0 | -280.5 | |
| 14.02 | -3.00 | 17.95 | -3.00 | 23.80 | 166.87 | 61.19 | 299.63 | 0.9240 | -453.2 | 999999 | |
| 3.20 | -3.00 | 3.70 | -3.00 | 22.15 | 164.47 | 58.79 | 298.75 | 0.9054 | -511.8 | 999999 | |
| 2.94 | -3.00 | 3.39 | -3.00 | 22.52 | 164.23 | 58.55 | 299.23 | 0.9048 | 257.3 | 999999 | |
| 2.25 | -3.00 | 2.78 | -3.00 | 24.33 | 165.55 | 59.87 | 300.62 | 0.9175 | -405.0 | 999999 | |
| 10.56 | -3.00 | 12.38 | -3.00 | 23.09 | 164.50 | 58.82 | 299.72 | 0.9080 | 378.7 | 999999 | |
| 3.29 | -3.00 | 3.54 | -3.00 | 21.11 | 162.60 | 56.92 | 298.34 | 0.8900 | 444.3 | 999999 | |
| 0.00 | 14.71 | 0.00 | 17.96 | 24.71 | 165.07 | 59.40 | 301.18 | 0.9156 | -418.0 | -403.2 | |
| 0.00 | 2.77 | 0.00 | 3.16 | 22.93 | 163.70 | 58.03 | 299.84 | 0.9025 | 227.0 | 173.4 | |
| 0.00 | 2.42 | 0.00 | 2.67 | 21.98 | 162.95 | 57.28 | 299.12 | 0.8949 | -280.0 | -266.6 | |
| 1.30 | -3.00 | 1.44 | -3.00 | 22.37 | 163.14 | 57.46 | 299.46 | 0.8973 | 121.0 | 999999 | |
| 5.71 | -3.00 | 6.30 | -3.00 | 22.52 | 162.77 | 57.09 | 299.76 | 0.8952 | 261.8 | 999999 | |
| 0.00 | 1.21 | 0.00 | 1.31 | 22.10 | 162.26 | 56.58 | 299.51 | 0.8905 | 235.0 | 186.2 | |
| 0.00 | 0.69 | 0.00 | 0.75 | 22.24 | 162.35 | 56.67 | 299.63 | 0.8916 | 138.0 | 147.4 | |
| 3.11 | 4.93 | 3.63 | 5.76 | 24.59 | 163.71 | 58.03 | 301.55 | 0.9070 | 310.9 | 40.6 | |
| 0.00 | 0.69 | 0.00 | 0.79 | 24.21 | 163.31 | 57.63 | 301.30 | 0.9034 | 257.0 | 199.0 | |
| 0.00 | 7.87 | 0.00 | 9.21 | 25.09 | 163.59 | 57.91 | 302.11 | 0.9076 | 261.0 | 203.7 | |
| 2.68 | 125.97 | 2.82 | 128.82 | 22.06 | 161.31 | 55.63 | 299.83 | 0.8838 | 514.8 | 473.9 | |
| 0.00 | 1.47 | 0.00 | 1.72 | 25.42 | 163.46 | 57.78 | 302.49 | 0.9077 | 369.0 | 310.4 | |
| 8.13 | -30.00 | 8.55 | -30.00 | 22.44 | 161.14 | 55.46 | 300.30 | 0.8838 | 436.3 | 999999 | |
| 0.00 | 2.34 | 0.00 | 2.69 | 25.29 | 162.93 | 57.25 | 302.56 | 0.9041 | -66.0 | -44.5 | |
| 3.46 | -30.00 | 3.55 | -30.00 | 22.13 | 160.45 | 54.77 | 300.25 | 0.8779 | 566.3 | 999999 | |
| 6.66 | 10.73 | 7.37 | 11.90 | 24.77 | 161.95 | 56.27 | 302.40 | 0.8963 | 313.1 | 163.1 | |
| 1.99 | 10.64 | 2.05 | 10.98 | 22.92 | 160.30 | 54.62 | 301.14 | 0.8793 | 551.0 | 425.3 | |
| 0.00 | 2.77 | 0.00 | 3.21 | 26.50 | 162.62 | 56.94 | 303.92 | 0.9057 | 503.0 | 403.6 | |
| 2.25 | -30.00 | 2.26 | -30.00 | 22.34 | 159.57 | 53.89 | 300.83 | 0.8722 | 875.0 | 999999 | |
| 3.29 | -36.00 | 3.38 | -36.00 | 23.09 | 160.01 | 54.33 | 301.44 | 0.8778 | 628.3 | 999999 | |
| 2.25 | 147.69 | 2.35 | 157.00 | 23.83 | 160.23 | 54.55 | 302.12 | 0.8818 | 617.1 | 313.7 | |
| 0.00 | 2.51 | 0.00 | 2.85 | 26.47 | 162.05 | 56.37 | 304.11 | 0.9021 | 528.0 | 419.2 | |
| 0.00 | 1.64 | 0.00 | 1.89 | 26.70 | 162.23 | 56.55 | 304.28 | 0.9038 | 211.0 | 238.3 | |
| 26.82 | -40.00 | 28.53 | -40.00 | 24.65 | 160.59 | 54.91 | 302.83 | 0.8870 | 618.6 | 999999 | |
| 0.00 | 2.77 | 0.00 | 3.17 | 27.00 | 162.09 | 56.41 | 304.63 | 0.9039 | 210.0 | 216.8 | |
| 0.00 | 1.64 | 0.00 | 1.64 | 22.79 | 159.06 | 53.38 | 301.52 | 0.8700 | 586.0 | 548.9 | |
| 0.00 | 2.68 | 0.00 | 3.02 | 26.67 | 161.59 | 55.92 | 304.49 | 0.8998 | 317.0 | 266.9 | |
| 0.00 | 2.42 | 0.00 | 2.43 | 23.10 | 159.13 | 53.45 | 301.82 | 0.8716 | 618.0 | 578.5 | |
| 0.00 | 4.33 | 0.00 | 4.78 | 26.69 | 160.90 | 55.22 | 304.80 | 0.8956 | 337.0 | 307.7 | |
| 0.00 | 1.30 | 0.00 | 1.40 | 26.56 | 159.99 | 54.31 | 305.04 | 0.8893 | 36.0 | 79.1 | |
| 3.55 | 7.61 | 3.85 | 8.29 | 26.93 | 160.20 | 54.52 | 305.33 | 0.8919 | -191.8 | 170.6 | |
| 4.76 | 51.65 | 5.14 | 57.15 | 27.24 | 159.85 | 54.17 | 305.80 | 0.8906 | -515.3 | 121.1 | |
| 1.21 | -51.00 | 1.31 | -51.00 | 27.47 | 159.67 | 53.99 | 306.11 | 0.8903 | -850.3 | 999999 | |
| 0.69 | 1.90 | 0.68 | 1.86 | 24.26 | 157.53 | 51.85 | 303.73 | 0.8642 | 426.6 | 355.9 | |
| 0.00 | 0.95 | 0.00 | 1.01 | 27.01 | 159.28 | 53.60 | 305.80 | 0.8862 | -269.0 | -264.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
