SDO HMI 2011-04-28 18:59:06 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 7.92 | 0.00 | 4.71 | 11.62 | 113.86 | -29.04 | 60.58 | 0.5524 | -347.6 | -423.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-04-28 18:59:06 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.98 | 0.00 | 0.57 | 14.36 | 117.78 | -25.12 | 52.53 | 0.5202 | 693.0 | 508.7 | |
| 0.00 | 2.58 | 0.00 | 1.51 | 14.18 | 116.63 | -26.27 | 54.02 | 0.5324 | -693.0 | -561.6 | |
| 0.00 | 0.98 | 0.00 | 0.60 | 15.48 | 112.72 | -30.18 | 55.70 | 0.5888 | -666.0 | -554.5 | |
| 0.00 | 0.98 | 0.00 | 0.60 | 14.31 | 112.28 | -30.62 | 57.78 | 0.5855 | -449.0 | -365.3 | |
| 0.00 | 2.40 | 0.00 | 1.43 | 5.09 | 110.52 | -32.38 | 73.95 | 0.5573 | -623.0 | -615.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
