SDO HMI 2011-04-29 13:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 70.99 | 296.90 | 70.40 | 296.81 | 20.33 | 188.38 | 55.93 | 296.52 | 0.8683 | 8.7 | 100.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-04-29 13:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.53 | 123.37 | 0.61 | 137.80 | 20.19 | 192.82 | 60.37 | 294.94 | 0.9015 | 169.8 | -126.3 | |
| 15.23 | -1.00 | 17.10 | -1.00 | 20.10 | 192.50 | 60.05 | 294.93 | 0.8991 | -631.6 | 999999 | |
| 0.00 | 0.80 | 0.00 | 0.85 | 18.90 | 191.08 | 58.63 | 294.04 | 0.8864 | -467.0 | -379.6 | |
| 10.33 | -1.00 | 11.26 | -1.00 | 20.04 | 191.56 | 59.11 | 295.13 | 0.8924 | -784.2 | 999999 | |
| 0.00 | 0.71 | 0.00 | 0.72 | 19.05 | 189.41 | 56.96 | 294.70 | 0.8741 | -478.0 | -471.5 | |
| 0.00 | 1.07 | 0.00 | 1.10 | 20.49 | 189.44 | 56.99 | 296.27 | 0.8779 | -269.0 | -199.2 | |
| 1.96 | 5.79 | 1.92 | 5.66 | 18.68 | 188.23 | 55.78 | 294.66 | 0.8640 | -636.6 | -677.4 | |
| 0.00 | 3.12 | 0.00 | 3.17 | 20.34 | 189.12 | 56.67 | 296.21 | 0.8751 | -619.0 | -516.3 | |
| 2.76 | -7.00 | 2.70 | -7.00 | 18.87 | 188.21 | 55.76 | 294.88 | 0.8644 | -669.9 | 999999 | |
| 0.98 | 2.05 | 0.99 | 2.07 | 20.49 | 188.91 | 56.46 | 296.44 | 0.8739 | -554.3 | -421.2 | |
| 0.00 | 1.87 | 0.00 | 1.86 | 20.74 | 188.17 | 55.72 | 296.95 | 0.8690 | -348.0 | -294.0 | |
| 0.00 | 0.98 | 0.00 | 0.95 | 19.86 | 187.42 | 54.97 | 296.25 | 0.8607 | -474.0 | -386.4 | |
| 0.00 | 1.34 | 0.00 | 1.33 | 21.81 | 187.92 | 55.48 | 298.21 | 0.8700 | -571.0 | -404.3 | |
| 10.15 | 37.68 | 9.49 | 35.21 | 20.07 | 186.03 | 53.58 | 296.96 | 0.8500 | 537.5 | 184.0 | |
| 0.45 | -14.00 | 0.41 | -14.00 | 20.11 | 185.61 | 53.16 | 297.15 | 0.8468 | 688.8 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.99 | 20.30 | 185.55 | 53.10 | 297.39 | 0.8468 | 339.0 | 320.0 | |
| 0.00 | 0.98 | 0.00 | 0.90 | 19.85 | 185.17 | 52.72 | 297.03 | 0.8422 | 394.0 | 420.5 | |
| 0.00 | 1.34 | 0.00 | 1.22 | 20.31 | 185.12 | 52.67 | 297.56 | 0.8433 | 572.0 | 491.7 | |
| 1.43 | 15.05 | 1.34 | 14.01 | 21.66 | 185.60 | 53.15 | 298.89 | 0.8514 | -133.6 | 191.1 | |
| 1.60 | 2.41 | 1.47 | 2.20 | 20.53 | 184.96 | 52.51 | 297.86 | 0.8427 | 435.6 | 384.2 | |
| 0.00 | 1.25 | 0.00 | 1.15 | 20.80 | 185.10 | 52.65 | 298.12 | 0.8447 | 426.0 | 353.1 | |
| 7.04 | -19.00 | 6.54 | -19.00 | 21.64 | 185.20 | 52.76 | 299.01 | 0.8482 | 353.3 | 999999 | |
| 0.00 | 0.80 | 0.00 | 0.74 | 21.36 | 184.95 | 52.50 | 298.79 | 0.8452 | 402.0 | 371.1 | |
| 0.00 | 0.80 | 0.00 | 0.73 | 20.89 | 184.45 | 52.00 | 298.47 | 0.8396 | 362.0 | 348.9 | |
| 18.53 | 87.47 | 16.57 | 77.85 | 20.60 | 184.00 | 51.55 | 298.32 | 0.8348 | 846.1 | 496.4 | |
| 0.00 | 3.83 | 0.00 | 3.51 | 21.86 | 184.57 | 52.12 | 299.50 | 0.8438 | 632.0 | 458.2 | |
| 0.00 | 1.78 | 0.00 | 1.59 | 21.37 | 183.53 | 51.08 | 299.36 | 0.8335 | 651.0 | 570.2 | |
| 0.00 | 1.34 | 0.00 | 1.20 | 22.10 | 183.48 | 51.03 | 300.20 | 0.8356 | 448.0 | 364.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
