SDO HMI 2011-05-01 04:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.22 | 15.97 | 11.40 | 24.60 | 15.08 | 180.19 | 69.23 | 287.51 | 0.9476 | -127.1 | -72.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-01 04:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.54 | 0.00 | 0.89 | 14.86 | 181.72 | 70.76 | 287.00 | 0.9556 | 343.0 | 335.3 | |
| 1.96 | 4.19 | 3.16 | 6.79 | 14.64 | 181.27 | 70.31 | 286.85 | 0.9532 | -268.8 | -177.8 | |
| 4.01 | 5.44 | 6.47 | 8.79 | 15.16 | 181.10 | 70.14 | 287.42 | 0.9528 | -376.0 | -137.9 | |
| 0.00 | 1.52 | 0.00 | 2.36 | 15.12 | 180.42 | 69.46 | 287.49 | 0.9492 | -563.0 | -500.0 | |
| 1.25 | 2.14 | 1.77 | 3.03 | 15.38 | 178.36 | 67.41 | 288.14 | 0.9382 | 178.6 | 121.0 | |
| 0.00 | 1.07 | 0.00 | 1.40 | 15.38 | 176.53 | 65.58 | 288.50 | 0.9274 | 152.0 | 154.6 | |
| 0.00 | 0.45 | 0.00 | 0.57 | 15.85 | 175.83 | 64.88 | 289.13 | 0.9236 | 434.0 | 383.6 | |
| 0.00 | 0.62 | 0.00 | 0.77 | 16.03 | 174.77 | 63.81 | 289.56 | 0.9170 | 516.0 | 398.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
