SDO HMI 2011-05-01 10:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.70 | 108.11 | 57.23 | 379.78 | 20.45 | 186.81 | 79.14 | 291.49 | 0.9870 | 324.1 | 5.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-01 10:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.57 | 17.30 | 27.71 | 143.35 | 19.96 | 192.21 | 84.54 | 290.35 | 0.9982 | 366.4 | 62.4 | |
| 0.00 | 2.41 | 0.00 | 7.89 | 19.63 | 186.89 | 79.22 | 290.61 | 0.9892 | -91.0 | -28.7 | |
| 2.05 | 83.49 | 5.31 | 215.65 | 20.77 | 184.17 | 76.51 | 292.12 | 0.9823 | -159.6 | -28.1 | |
| 5.80 | -3.00 | 14.27 | -3.00 | 20.63 | 183.53 | 75.86 | 292.07 | 0.9802 | 377.5 | 999999 | |
| 4.28 | -3.00 | 9.94 | -3.00 | 20.80 | 182.74 | 75.07 | 292.36 | 0.9777 | 538.3 | 999999 | |
| 0.00 | 0.71 | 0.00 | 2.01 | 22.14 | 184.92 | 77.25 | 293.39 | 0.9851 | -414.0 | -350.4 | |
| 0.00 | 1.61 | 0.00 | 4.07 | 21.70 | 183.87 | 76.20 | 293.10 | 0.9818 | 284.0 | 270.7 | |
| 0.00 | 2.59 | 0.00 | 6.81 | 22.12 | 184.15 | 76.48 | 293.48 | 0.9829 | 25.0 | -38.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
