SDO HMI 2011-05-02 03:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 41.77 | 287.47 | 27.77 | 189.99 | 17.60 | 62.60 | -35.69 | 57.26 | 0.6628 | -689.5 | -274.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-02 03:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.16 | 0.00 | 0.74 | 17.13 | 64.85 | -33.43 | 56.33 | 0.6349 | 688.0 | 574.8 | |
| 37.84 | 267.39 | 24.79 | 175.26 | 17.52 | 63.16 | -35.13 | 57.03 | 0.6564 | -1185.9 | -338.2 | |
| 0.00 | 2.32 | 0.00 | 1.62 | 19.28 | 59.60 | -38.69 | 57.08 | 0.7052 | 745.0 | 508.8 | |
| 0.00 | 0.62 | 0.00 | 0.45 | 18.58 | 57.13 | -41.16 | 59.41 | 0.7270 | 185.0 | 170.9 | |
| 0.00 | 4.11 | 0.00 | 2.94 | 18.05 | 57.19 | -41.09 | 60.03 | 0.7237 | 509.0 | 568.1 | |
| 0.00 | 1.07 | 0.00 | 0.77 | 18.16 | 56.95 | -41.34 | 60.03 | 0.7268 | 657.0 | 544.3 | |
| 0.00 | 0.89 | 0.00 | 0.68 | 20.13 | 54.35 | -43.93 | 58.99 | 0.7623 | 557.0 | 500.7 | |
| 0.00 | 1.16 | 0.00 | 0.90 | 21.22 | 53.63 | -44.66 | 58.06 | 0.7744 | 544.0 | 395.3 | |
| 3.93 | 8.75 | 2.98 | 6.63 | 18.39 | 53.74 | -44.55 | 61.39 | 0.7605 | 517.0 | 632.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
