SDO HMI 2011-05-02 13:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 37.21 | 100.00 | 28.40 | 76.97 | 16.78 | 46.88 | -45.92 | 64.03 | 0.7671 | -162.9 | -115.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-02 13:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.34 | 0.00 | 1.00 | 16.13 | 48.25 | -44.55 | 64.22 | 0.7507 | -690.0 | -615.4 | |
| 20.43 | 50.41 | 15.43 | 38.05 | 16.83 | 47.91 | -44.89 | 63.52 | 0.7571 | -816.5 | -436.3 | |
| 1.07 | 2.68 | 0.82 | 2.05 | 17.81 | 47.60 | -45.20 | 62.45 | 0.7643 | -489.4 | -518.7 | |
| 4.10 | 7.76 | 3.06 | 5.79 | 15.82 | 48.16 | -44.64 | 64.65 | 0.7504 | -706.1 | -514.9 | |
| 1.34 | 2.32 | 1.02 | 1.77 | 17.29 | 47.63 | -45.17 | 63.07 | 0.7618 | -367.7 | -252.3 | |
| 0.00 | 1.61 | 0.00 | 1.26 | 19.08 | 46.98 | -45.82 | 61.20 | 0.7756 | -548.0 | -482.8 | |
| 2.14 | -2.00 | 1.61 | -2.00 | 16.26 | 47.77 | -45.03 | 64.29 | 0.7562 | -493.1 | 999999 | |
| 0.00 | 0.98 | 0.00 | 0.77 | 19.19 | 46.81 | -46.00 | 61.16 | 0.7778 | -482.0 | -429.5 | |
| 0.00 | 3.12 | 0.00 | 2.35 | 15.56 | 47.66 | -45.15 | 65.21 | 0.7546 | 173.0 | 14.0 | |
| 0.00 | 0.54 | 0.00 | 0.41 | 15.97 | 47.13 | -45.67 | 64.92 | 0.7616 | -215.0 | -219.3 | |
| 0.00 | 0.98 | 0.00 | 0.76 | 16.95 | 46.79 | -46.02 | 63.87 | 0.7689 | 264.0 | 252.4 | |
| 0.00 | 0.80 | 0.00 | 0.64 | 18.24 | 45.66 | -47.15 | 62.80 | 0.7850 | -502.0 | -396.6 | |
| 0.00 | 0.98 | 0.00 | 0.79 | 18.80 | 45.40 | -47.40 | 62.24 | 0.7897 | 645.0 | 532.0 | |
| 0.00 | 1.25 | 0.00 | 1.01 | 18.69 | 45.07 | -47.74 | 62.52 | 0.7924 | 663.0 | 542.1 | |
| 0.00 | 1.52 | 0.00 | 1.19 | 16.20 | 45.78 | -47.02 | 65.21 | 0.7761 | 458.0 | 363.5 | |
| 0.00 | 0.98 | 0.00 | 0.77 | 16.66 | 45.49 | -47.31 | 64.76 | 0.7807 | 545.0 | 542.1 | |
| 2.77 | 3.12 | 2.15 | 2.42 | 15.08 | 45.80 | -47.01 | 66.57 | 0.7720 | 651.0 | 578.5 | |
| 3.30 | 4.10 | 2.64 | 3.29 | 16.80 | 44.84 | -47.96 | 64.87 | 0.7876 | 679.8 | 658.7 | |
| 0.00 | 1.96 | 0.00 | 1.57 | 16.48 | 44.71 | -48.10 | 65.30 | 0.7878 | 702.0 | 567.3 | |
| 0.00 | 0.80 | 0.00 | 0.67 | 18.66 | 43.82 | -48.98 | 63.07 | 0.8040 | 497.0 | 476.8 | |
| 0.45 | 1.16 | 0.36 | 0.94 | 17.08 | 44.31 | -48.49 | 64.74 | 0.7937 | 511.2 | 450.4 | |
| 1.61 | 4.28 | 1.31 | 3.48 | 16.91 | 43.99 | -48.82 | 65.08 | 0.7962 | 651.4 | 491.2 | |
| 0.00 | 3.30 | 0.00 | 2.67 | 16.13 | 44.11 | -48.69 | 65.96 | 0.7924 | 626.0 | 454.4 | |
| 0.00 | 0.89 | 0.00 | 0.73 | 17.15 | 43.76 | -49.04 | 64.89 | 0.7992 | 418.0 | 374.9 | |
| 0.00 | 0.80 | 0.00 | 0.67 | 18.20 | 43.37 | -49.44 | 63.80 | 0.8066 | 449.0 | 443.8 | |
| 0.00 | 1.78 | 0.00 | 1.47 | 17.00 | 43.57 | -49.23 | 65.14 | 0.8005 | 520.0 | 405.3 | |
| 0.00 | 0.54 | 0.00 | 0.45 | 17.67 | 42.48 | -50.32 | 64.76 | 0.8129 | 342.0 | 364.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
