SDO HMI 2011-05-02 15:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.96 | 87.41 | 12.63 | 52.32 | -16.84 | 123.93 | 32.23 | 245.46 | 0.5631 | 99.4 | 120.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-02 15:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.67 | 21.32 | 4.70 | 13.05 | -16.34 | 126.26 | 34.56 | 247.56 | 0.5911 | 795.1 | 589.3 | |
| 0.00 | 0.98 | 0.00 | 0.60 | -17.08 | 126.22 | 34.52 | 246.33 | 0.5937 | 606.0 | 475.9 | |
| 2.05 | 7.76 | 1.25 | 4.72 | -15.92 | 125.79 | 34.09 | 248.03 | 0.5834 | 976.8 | 707.3 | |
| 0.00 | 1.16 | 0.00 | 0.70 | -16.33 | 125.49 | 33.79 | 247.21 | 0.5812 | 293.0 | 242.4 | |
| 0.00 | 1.25 | 0.00 | 0.76 | -17.00 | 125.02 | 33.32 | 245.87 | 0.5778 | -651.0 | -459.9 | |
| 0.00 | 2.05 | 0.00 | 1.23 | -16.15 | 124.59 | 32.89 | 247.08 | 0.5685 | -507.0 | -365.0 | |
| 0.00 | 2.05 | 0.00 | 1.24 | -16.58 | 124.64 | 32.94 | 246.37 | 0.5709 | -629.0 | -499.9 | |
| 1.52 | 2.85 | 0.91 | 1.72 | -16.99 | 124.49 | 32.79 | 245.61 | 0.5708 | 722.0 | 541.4 | |
| 0.36 | 2.05 | 0.21 | 1.23 | -16.29 | 124.28 | 32.58 | 246.69 | 0.5649 | -691.0 | -589.8 | |
| 0.00 | 2.68 | 0.00 | 1.60 | -17.18 | 123.78 | 32.08 | 244.92 | 0.5623 | 902.0 | 670.9 | |
| 8.65 | 17.48 | 5.14 | 10.38 | -16.16 | 123.55 | 31.85 | 246.53 | 0.5547 | 930.8 | 523.8 | |
| 0.00 | 1.87 | 0.00 | 1.11 | -16.87 | 122.86 | 31.16 | 244.93 | 0.5488 | 576.0 | 489.5 | |
| 0.00 | 2.85 | 0.00 | 1.68 | -17.38 | 122.33 | 30.63 | 243.72 | 0.5444 | 836.0 | 603.5 | |
| 0.00 | 1.34 | 0.00 | 0.79 | -17.82 | 122.38 | 30.68 | 243.00 | 0.5472 | 811.0 | 608.4 | |
| 0.71 | 2.05 | 0.42 | 1.21 | -17.14 | 122.10 | 30.40 | 244.00 | 0.5401 | -565.8 | -525.7 | |
| 0.00 | 1.52 | 0.00 | 0.89 | -16.93 | 121.77 | 30.07 | 244.16 | 0.5347 | -878.0 | -718.7 | |
| 0.00 | 3.48 | 0.00 | 2.04 | -18.54 | 121.26 | 29.56 | 241.02 | 0.5368 | -795.0 | -697.3 | |
| 0.00 | 1.16 | 0.00 | 0.68 | -18.31 | 120.74 | 29.04 | 241.06 | 0.5287 | -606.0 | -586.5 | |
| 0.00 | 1.34 | 0.00 | 0.78 | -18.59 | 120.76 | 29.06 | 240.58 | 0.5306 | -777.0 | -648.3 | |
| 0.00 | 0.98 | 0.00 | 0.57 | -18.41 | 120.47 | 28.77 | 240.69 | 0.5258 | -737.0 | -564.1 | |
| 0.00 | 1.34 | 0.00 | 0.78 | -18.51 | 120.31 | 28.61 | 240.39 | 0.5243 | -859.0 | -749.3 | |
| 0.00 | 3.39 | 0.00 | 1.96 | -18.23 | 120.19 | 28.49 | 240.79 | 0.5210 | -838.0 | -756.2 | |
| 0.00 | 2.05 | 0.00 | 1.20 | -19.64 | 120.38 | 28.68 | 238.50 | 0.5322 | -624.0 | -563.7 | |
| 0.00 | 1.43 | 0.00 | 0.83 | -18.40 | 120.00 | 28.30 | 240.37 | 0.5196 | -760.0 | -595.2 | |
| 0.00 | 0.98 | 0.00 | 0.57 | -19.28 | 119.87 | 28.17 | 238.73 | 0.5234 | -779.0 | -715.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
