SDO HMI 2011-05-02 21:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 48.99 | 311.05 | 29.21 | 185.49 | 17.67 | 62.15 | -26.23 | 49.20 | 0.5579 | -612.3 | -318.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-02 21:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.98 | 289.09 | 0.58 | 171.40 | 17.86 | 62.95 | -25.43 | 48.12 | 0.5510 | -672.1 | -382.0 | |
| 1.43 | -1.00 | 0.84 | -1.00 | 17.11 | 62.92 | -25.45 | 49.22 | 0.5445 | -1140.4 | 999999 | |
| 2.32 | -1.00 | 1.38 | -1.00 | 17.87 | 62.74 | -25.64 | 48.34 | 0.5534 | -771.8 | 999999 | |
| 40.33 | -1.00 | 23.91 | -1.00 | 17.51 | 62.62 | -25.76 | 48.98 | 0.5515 | -1250.7 | 999999 | |
| 0.00 | 1.43 | 0.00 | 0.90 | 22.81 | 60.47 | -27.91 | 44.18 | 0.6214 | -530.0 | -405.6 | |
| 0.00 | 1.34 | 0.00 | 0.84 | 18.28 | 57.42 | -30.96 | 52.84 | 0.6151 | 881.0 | 805.4 | |
| 1.52 | 1.61 | 0.95 | 1.01 | 18.16 | 57.26 | -31.12 | 53.15 | 0.6159 | 691.9 | 834.0 | |
| 0.00 | 2.14 | 0.00 | 1.35 | 18.59 | 57.06 | -31.32 | 52.73 | 0.6213 | 627.0 | 518.5 | |
| 0.98 | 1.52 | 0.62 | 0.95 | 18.23 | 57.06 | -31.32 | 53.22 | 0.6187 | 738.5 | 668.8 | |
| 0.00 | 1.52 | 0.00 | 0.96 | 18.37 | 56.81 | -31.57 | 53.23 | 0.6225 | 623.0 | 520.8 | |
| 0.00 | 0.89 | 0.00 | 0.57 | 18.73 | 56.66 | -31.72 | 52.87 | 0.6268 | 626.0 | 504.0 | |
| 0.00 | 1.61 | 0.00 | 1.02 | 18.54 | 56.66 | -31.72 | 53.13 | 0.6253 | 582.0 | 495.7 | |
| 0.00 | 2.32 | 0.00 | 1.48 | 18.84 | 56.33 | -32.05 | 52.98 | 0.6312 | 725.0 | 541.0 | |
| 0.00 | 1.78 | 0.00 | 1.19 | 22.62 | 54.87 | -33.51 | 49.34 | 0.6742 | 531.0 | 470.1 | |
| 0.00 | 1.16 | 0.00 | 0.75 | 19.57 | 55.53 | -32.85 | 52.68 | 0.6451 | 526.0 | 472.8 | |
| 0.00 | 1.16 | 0.00 | 0.79 | 23.04 | 53.68 | -34.70 | 49.74 | 0.6888 | 583.0 | 509.2 | |
| 0.00 | 1.25 | 0.00 | 0.82 | 18.39 | 53.95 | -34.43 | 55.43 | 0.6538 | 756.0 | 542.6 | |
| 1.43 | 2.23 | 0.93 | 1.46 | 18.20 | 53.72 | -34.66 | 55.84 | 0.6551 | 699.9 | 559.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
