SDO HMI 2011-05-03 10:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 48.93 | 224.58 | 31.09 | 143.37 | 16.67 | 47.76 | -33.47 | 57.10 | 0.6311 | -172.2 | -127.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-03 10:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.80 | 0.00 | 0.49 | 15.48 | 51.32 | -29.92 | 56.03 | 0.5818 | 690.0 | 531.2 | |
| 0.00 | 1.25 | 0.00 | 0.78 | 16.47 | 49.72 | -31.52 | 55.92 | 0.6075 | -771.0 | -615.2 | |
| 6.34 | 177.42 | 3.97 | 112.17 | 16.49 | 49.16 | -32.08 | 56.34 | 0.6141 | -1027.5 | -317.9 | |
| 2.50 | -3.00 | 1.57 | -3.00 | 16.82 | 48.91 | -32.33 | 56.06 | 0.6192 | -868.2 | 999999 | |
| 1.16 | -3.00 | 0.73 | -3.00 | 16.40 | 48.95 | -32.29 | 56.62 | 0.6159 | -868.1 | 999999 | |
| 1.16 | -3.00 | 0.72 | -3.00 | 15.82 | 49.06 | -32.18 | 57.37 | 0.6107 | -737.8 | 999999 | |
| 3.39 | -3.00 | 2.13 | -3.00 | 15.93 | 48.63 | -32.61 | 57.54 | 0.6164 | -588.2 | 999999 | |
| 21.52 | -3.00 | 13.64 | -3.00 | 16.94 | 48.36 | -32.88 | 56.32 | 0.6263 | -937.1 | 999999 | |
| 7.14 | -3.00 | 4.51 | -3.00 | 16.29 | 48.41 | -32.83 | 57.19 | 0.6214 | -831.9 | 999999 | |
| 0.00 | 0.89 | 0.00 | 0.57 | 17.68 | 47.64 | -33.60 | 55.85 | 0.6394 | -538.0 | -367.7 | |
| 0.00 | 1.88 | 0.00 | 1.22 | 18.32 | 47.04 | -34.20 | 55.43 | 0.6503 | -654.0 | -489.6 | |
| 0.63 | 2.68 | 0.40 | 1.71 | 16.18 | 47.18 | -34.05 | 58.24 | 0.6347 | 726.7 | 539.7 | |
| 0.00 | 0.98 | 0.00 | 0.63 | 16.57 | 47.07 | -34.17 | 57.78 | 0.6385 | 709.0 | 664.9 | |
| 0.00 | 1.88 | 0.00 | 1.19 | 14.22 | 46.71 | -34.52 | 61.35 | 0.6283 | 881.0 | 714.7 | |
| 0.00 | 0.89 | 0.00 | 0.57 | 14.17 | 46.49 | -34.74 | 61.57 | 0.6305 | 373.0 | 329.8 | |
| 0.00 | 2.50 | 0.00 | 1.60 | 14.85 | 46.18 | -35.06 | 60.81 | 0.6382 | 515.0 | 507.9 | |
| 0.00 | 1.25 | 0.00 | 0.84 | 19.06 | 44.94 | -36.30 | 55.94 | 0.6777 | 600.0 | 474.9 | |
| 0.00 | 0.98 | 0.00 | 0.66 | 18.90 | 44.86 | -36.37 | 56.20 | 0.6775 | 671.0 | 482.5 | |
| 0.00 | 0.89 | 0.00 | 0.58 | 14.84 | 45.68 | -35.55 | 61.15 | 0.6440 | 618.0 | 463.6 | |
| 0.00 | 0.36 | 0.00 | 0.24 | 19.07 | 44.70 | -36.54 | 56.09 | 0.6803 | 343.0 | 347.8 | |
| 0.00 | 2.14 | 0.00 | 1.40 | 16.29 | 45.27 | -35.96 | 59.40 | 0.6572 | 552.0 | 573.8 | |
| 0.00 | 1.88 | 0.00 | 1.24 | 16.18 | 44.83 | -36.41 | 59.83 | 0.6616 | 784.0 | 718.2 | |
| 0.00 | 1.88 | 0.00 | 1.24 | 16.48 | 44.72 | -36.51 | 59.50 | 0.6645 | 858.0 | 670.5 | |
| 1.43 | 2.14 | 0.94 | 1.42 | 16.19 | 44.59 | -36.65 | 59.97 | 0.6644 | 729.7 | 723.8 | |
| 0.00 | 2.86 | 0.00 | 1.90 | 16.39 | 44.43 | -36.81 | 59.80 | 0.6673 | 750.0 | 631.7 | |
| 0.00 | 1.79 | 0.00 | 1.20 | 16.86 | 43.96 | -37.27 | 59.46 | 0.6752 | 795.0 | 618.2 | |
| 0.00 | 1.16 | 0.00 | 0.79 | 18.27 | 43.54 | -37.70 | 57.87 | 0.6879 | 597.0 | 513.5 | |
| 0.00 | 1.88 | 0.00 | 1.25 | 16.48 | 43.89 | -37.34 | 60.02 | 0.6738 | 656.0 | 600.3 | |
| 0.00 | 0.54 | 0.00 | 0.37 | 18.62 | 43.08 | -38.15 | 57.71 | 0.6948 | 422.0 | 501.5 | |
| 0.00 | 1.16 | 0.00 | 0.79 | 17.87 | 43.07 | -38.16 | 58.68 | 0.6906 | 723.0 | 526.1 | |
| 0.00 | 2.14 | 0.00 | 1.48 | 18.50 | 42.83 | -38.40 | 58.02 | 0.6968 | 477.0 | 418.8 | |
| 3.66 | 6.25 | 2.48 | 4.23 | 16.90 | 43.15 | -38.08 | 59.91 | 0.6843 | 734.0 | 682.6 | |
| 0.00 | 1.61 | 0.00 | 1.09 | 17.42 | 43.03 | -38.21 | 59.30 | 0.6886 | 669.0 | 556.4 | |
| 0.00 | 2.50 | 0.00 | 1.72 | 18.25 | 42.65 | -38.58 | 58.46 | 0.6973 | 490.0 | 398.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
