SDO HMI 2011-05-04 04:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.30 | 20.28 | 2.70 | 16.05 | 13.32 | 119.85 | 48.55 | 290.60 | 0.7810 | -256.5 | 91.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-04 04:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.23 | 2.95 | 1.86 | 2.46 | 13.52 | 122.35 | 51.05 | 289.96 | 0.8067 | -551.4 | -469.6 | |
| 0.00 | 1.07 | 0.00 | 0.89 | 13.35 | 122.15 | 50.85 | 289.82 | 0.8043 | -689.0 | -608.6 | |
| 0.00 | 1.97 | 0.00 | 1.62 | 13.27 | 121.83 | 50.53 | 289.83 | 0.8009 | -668.0 | -573.5 | |
| 0.00 | 1.61 | 0.00 | 1.27 | 12.85 | 119.84 | 48.54 | 289.98 | 0.7797 | 510.0 | 422.9 | |
| 0.00 | 1.52 | 0.00 | 1.20 | 13.13 | 119.87 | 48.57 | 290.32 | 0.7808 | 393.0 | 330.5 | |
| 1.07 | 7.95 | 0.84 | 6.23 | 13.05 | 119.47 | 48.17 | 290.36 | 0.7765 | 761.8 | 573.9 | |
| 0.00 | 1.61 | 0.00 | 1.23 | 13.06 | 118.41 | 47.11 | 290.75 | 0.7654 | -540.0 | -436.6 | |
| 0.00 | 0.71 | 0.00 | 0.51 | 14.21 | 113.63 | 42.33 | 294.21 | 0.7180 | -567.0 | -419.9 | |
| 0.00 | 0.89 | 0.00 | 0.64 | 16.41 | 113.50 | 42.20 | 297.12 | 0.7262 | -541.0 | -484.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
