SDO HMI 2011-05-04 06:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 63.00 | 312.44 | 35.93 | 178.75 | 16.64 | 48.09 | -22.12 | 46.14 | 0.5018 | -298.4 | -220.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-04 06:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.16 | 0.00 | 0.65 | 16.32 | 50.34 | -19.86 | 43.69 | 0.4740 | -773.0 | -727.2 | |
| 7.51 | 247.50 | 4.25 | 140.71 | 16.89 | 49.71 | -20.50 | 43.73 | 0.4867 | -923.1 | -435.7 | |
| 12.51 | -2.00 | 7.08 | -2.00 | 16.57 | 49.44 | -20.77 | 44.56 | 0.4862 | -1187.9 | 999999 | |
| 0.00 | 0.89 | 0.00 | 0.50 | 15.93 | 49.24 | -20.96 | 45.81 | 0.4818 | -701.0 | -607.2 | |
| 1.34 | -2.00 | 0.76 | -2.00 | 16.42 | 49.12 | -21.09 | 45.23 | 0.4881 | -921.2 | 999999 | |
| 0.00 | 3.13 | 0.00 | 1.76 | 15.39 | 49.24 | -20.97 | 46.67 | 0.4763 | -830.0 | -627.3 | |
| 18.23 | -2.00 | 10.38 | -2.00 | 16.71 | 48.82 | -21.39 | 45.18 | 0.4945 | -996.1 | 999999 | |
| 9.20 | -2.00 | 5.26 | -2.00 | 16.76 | 48.37 | -21.84 | 45.69 | 0.4997 | -881.1 | 999999 | |
| 0.45 | -2.00 | 0.25 | -2.00 | 16.31 | 48.42 | -21.78 | 46.31 | 0.4946 | -730.8 | 999999 | |
| 5.90 | -2.00 | 3.37 | -2.00 | 16.38 | 48.08 | -22.13 | 46.64 | 0.4992 | -664.7 | 999999 | |
| 1.52 | -2.00 | 0.87 | -2.00 | 16.12 | 48.04 | -22.17 | 47.08 | 0.4970 | -620.4 | 999999 | |
| 0.00 | 0.80 | 0.00 | 0.46 | 16.76 | 47.28 | -22.93 | 47.06 | 0.5116 | -513.0 | -421.9 | |
| 0.00 | 2.50 | 0.00 | 1.44 | 16.92 | 47.12 | -23.09 | 47.01 | 0.5150 | -472.0 | -418.6 | |
| 0.00 | 1.61 | 0.00 | 0.94 | 18.66 | 46.67 | -23.54 | 45.05 | 0.5368 | -845.0 | -576.4 | |
| 0.71 | 1.52 | 0.42 | 0.89 | 18.73 | 46.27 | -23.93 | 45.40 | 0.5417 | -764.8 | -660.6 | |
| 0.00 | 3.93 | 0.00 | 2.27 | 16.39 | 46.57 | -23.64 | 48.46 | 0.5160 | 737.0 | 663.1 | |
| 0.00 | 0.98 | 0.00 | 0.56 | 15.05 | 46.32 | -23.89 | 50.82 | 0.5064 | 861.0 | 706.7 | |
| 0.00 | 1.43 | 0.00 | 0.82 | 14.89 | 46.24 | -23.97 | 51.17 | 0.5060 | 843.0 | 704.2 | |
| 1.07 | 3.31 | 0.62 | 1.92 | 16.18 | 45.80 | -24.41 | 49.65 | 0.5228 | 819.7 | 647.0 | |
| 1.52 | 8.58 | 0.88 | 5.00 | 15.88 | 45.22 | -24.99 | 50.76 | 0.5267 | 918.8 | 838.0 | |
| 0.00 | 0.98 | 0.00 | 0.59 | 18.65 | 44.74 | -25.47 | 47.24 | 0.5571 | 683.0 | 545.6 | |
| 1.70 | 2.95 | 1.00 | 1.73 | 16.92 | 44.76 | -25.45 | 49.69 | 0.5412 | 865.5 | 809.0 | |
| 0.00 | 1.25 | 0.00 | 0.73 | 16.70 | 44.79 | -25.42 | 49.99 | 0.5388 | 1013.0 | 918.2 | |
| 0.00 | 0.98 | 0.00 | 0.58 | 16.12 | 44.77 | -25.44 | 50.88 | 0.5340 | 940.0 | 872.1 | |
| 0.00 | 1.43 | 0.00 | 0.84 | 16.64 | 44.59 | -25.62 | 50.29 | 0.5406 | 938.0 | 770.7 | |
| 0.00 | 1.52 | 0.00 | 0.89 | 16.00 | 44.50 | -25.70 | 51.35 | 0.5360 | 987.0 | 808.6 | |
| 0.00 | 3.48 | 0.00 | 2.06 | 16.81 | 44.35 | -25.85 | 50.29 | 0.5447 | 876.0 | 607.8 | |
| 0.00 | 0.98 | 0.00 | 0.59 | 18.37 | 44.04 | -26.17 | 48.37 | 0.5621 | 650.0 | 517.9 | |
| 0.00 | 3.57 | 0.00 | 2.09 | 15.88 | 44.35 | -25.86 | 51.70 | 0.5367 | 714.0 | 598.0 | |
| 0.00 | 1.07 | 0.00 | 0.64 | 16.85 | 43.89 | -26.32 | 50.71 | 0.5504 | 758.0 | 688.4 | |
| 0.00 | 0.98 | 0.00 | 0.58 | 16.08 | 43.97 | -26.24 | 51.78 | 0.5428 | 926.0 | 745.6 | |
| 0.00 | 1.70 | 0.00 | 1.02 | 18.04 | 43.45 | -26.75 | 49.45 | 0.5655 | 866.0 | 653.3 | |
| 1.34 | 2.59 | 0.79 | 1.53 | 16.48 | 43.63 | -26.58 | 51.54 | 0.5501 | 760.3 | 686.3 | |
| 0.00 | 1.70 | 0.00 | 1.01 | 16.55 | 43.48 | -26.73 | 51.59 | 0.5524 | 416.0 | 435.1 | |
| 0.00 | 1.25 | 0.00 | 0.75 | 17.95 | 43.15 | -27.06 | 49.89 | 0.5681 | 856.0 | 604.9 | |
| 0.00 | 4.65 | 0.00 | 2.79 | 17.50 | 42.97 | -27.24 | 50.70 | 0.5662 | 835.0 | 704.6 | |
| 0.00 | 0.98 | 0.00 | 0.59 | 17.80 | 42.78 | -27.43 | 50.47 | 0.5709 | 630.0 | 523.6 | |
| 0.00 | 3.04 | 0.00 | 1.82 | 16.73 | 42.74 | -27.47 | 52.05 | 0.5624 | 832.0 | 619.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
