SDO HMI 2011-05-04 11:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 60.47 | 345.68 | 32.46 | 185.47 | 17.83 | 61.20 | -6.27 | 15.61 | 0.3855 | -682.5 | -350.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-04 11:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 48.50 | 317.36 | 25.96 | 169.92 | 17.67 | 61.72 | -5.75 | 14.60 | 0.3803 | -1309.2 | -408.9 | |
| 3.57 | -1.00 | 1.92 | -1.00 | 18.07 | 61.26 | -6.21 | 15.43 | 0.3884 | -903.7 | 999999 | |
| 1.34 | -1.00 | 0.72 | -1.00 | 18.23 | 61.22 | -6.25 | 15.40 | 0.3911 | -670.3 | 999999 | |
| 0.00 | 0.89 | 0.00 | 0.48 | 18.22 | 59.17 | -8.30 | 20.09 | 0.4009 | -792.0 | -649.6 | |
| 0.00 | 3.22 | 0.00 | 1.74 | 18.61 | 59.05 | -8.42 | 20.00 | 0.4074 | -660.0 | -476.8 | |
| 1.79 | 2.41 | 0.97 | 1.31 | 18.50 | 56.95 | -10.51 | 24.53 | 0.4185 | 952.0 | 880.6 | |
| 0.00 | 1.97 | 0.00 | 1.07 | 18.77 | 56.91 | -10.56 | 24.36 | 0.4226 | 901.0 | 673.9 | |
| 0.00 | 2.95 | 0.00 | 1.61 | 18.25 | 56.26 | -11.21 | 26.22 | 0.4197 | 573.0 | 623.8 | |
| 0.00 | 1.34 | 0.00 | 0.76 | 23.18 | 55.85 | -11.62 | 22.23 | 0.4915 | 735.0 | 614.1 | |
| 0.00 | 0.89 | 0.00 | 0.49 | 18.45 | 56.18 | -11.29 | 26.16 | 0.4230 | 614.0 | 455.8 | |
| 0.00 | 1.16 | 0.00 | 0.64 | 19.10 | 56.04 | -11.43 | 25.73 | 0.4332 | 716.0 | 483.2 | |
| 0.00 | 1.43 | 0.00 | 0.83 | 25.35 | 55.40 | -12.07 | 21.23 | 0.5238 | 834.0 | 673.4 | |
| 0.00 | 1.25 | 0.00 | 0.68 | 17.99 | 55.98 | -11.49 | 27.06 | 0.4181 | 768.0 | 556.3 | |
| 2.68 | 3.57 | 1.46 | 1.95 | 18.03 | 55.56 | -11.91 | 27.86 | 0.4217 | -671.8 | -506.7 | |
| 0.00 | 1.70 | 0.00 | 0.94 | 18.97 | 54.41 | -13.06 | 28.96 | 0.4431 | 883.0 | 663.5 | |
| 2.59 | 4.11 | 1.43 | 2.26 | 18.41 | 54.13 | -13.34 | 30.14 | 0.4378 | 863.7 | 540.4 | |
| 0.00 | 1.43 | 0.00 | 0.79 | 19.18 | 53.44 | -14.03 | 30.47 | 0.4534 | 790.0 | 650.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
