SDO HMI 2011-05-04 15:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 56.78 | 341.18 | 30.34 | 182.79 | 18.07 | 60.95 | -4.32 | 10.63 | 0.3821 | -534.4 | -326.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-04 15:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.80 | 305.65 | 0.43 | 163.12 | 18.37 | 61.79 | -3.48 | 8.65 | 0.3839 | -445.7 | -440.5 | |
| 44.29 | -1.00 | 23.63 | -1.00 | 17.66 | 61.68 | -3.59 | 9.25 | 0.3728 | -1411.6 | 999999 | |
| 0.00 | 0.71 | 0.00 | 0.40 | 23.31 | 61.11 | -4.15 | 8.30 | 0.4628 | -669.0 | -506.9 | |
| 0.00 | 2.14 | 0.00 | 1.15 | 18.70 | 61.24 | -4.03 | 9.84 | 0.3906 | -718.0 | -522.6 | |
| 9.64 | -1.00 | 5.16 | -1.00 | 18.05 | 61.16 | -4.11 | 10.35 | 0.3805 | -946.7 | 999999 | |
| 0.00 | 3.39 | 0.00 | 1.84 | 18.51 | 56.98 | -8.28 | 19.80 | 0.4051 | 1046.0 | 913.1 | |
| 0.00 | 1.07 | 0.00 | 0.58 | 18.80 | 56.93 | -8.33 | 19.64 | 0.4098 | 762.0 | 623.9 | |
| 0.00 | 0.98 | 0.00 | 0.53 | 17.66 | 56.89 | -8.37 | 20.77 | 0.3929 | 897.0 | 650.4 | |
| 0.00 | 2.68 | 0.00 | 1.45 | 18.38 | 56.38 | -8.89 | 21.23 | 0.4066 | 752.0 | 617.5 | |
| 0.00 | 1.34 | 0.00 | 0.72 | 18.22 | 56.35 | -8.91 | 21.44 | 0.4044 | 946.0 | 683.5 | |
| 0.00 | 1.16 | 0.00 | 0.65 | 23.21 | 55.98 | -9.28 | 18.09 | 0.4795 | 675.0 | 570.6 | |
| 0.00 | 1.43 | 0.00 | 0.77 | 18.22 | 56.13 | -9.14 | 21.93 | 0.4057 | 784.0 | 450.6 | |
| 0.00 | 1.25 | 0.00 | 0.68 | 19.04 | 56.05 | -9.22 | 21.32 | 0.4182 | 810.0 | 689.9 | |
| 0.00 | 2.68 | 0.00 | 1.51 | 23.08 | 55.66 | -9.61 | 18.77 | 0.4792 | 236.0 | 266.4 | |
| 0.00 | 3.21 | 0.00 | 1.82 | 23.28 | 55.64 | -9.62 | 18.65 | 0.4822 | 691.0 | 543.9 | |
| 0.00 | 1.43 | 0.00 | 0.82 | 25.45 | 55.44 | -9.82 | 17.51 | 0.5141 | 825.0 | 551.7 | |
| 1.34 | 2.05 | 0.73 | 1.11 | 18.13 | 55.91 | -9.36 | 22.50 | 0.4057 | -542.9 | -430.9 | |
| 0.00 | 0.89 | 0.00 | 0.51 | 24.69 | 55.06 | -10.20 | 18.65 | 0.5051 | 756.0 | 530.5 | |
| 0.71 | 3.13 | 0.39 | 1.71 | 18.51 | 54.10 | -11.16 | 25.84 | 0.4229 | 1088.6 | 884.2 | |
| 0.00 | 1.61 | 0.00 | 0.88 | 18.88 | 53.49 | -11.77 | 26.64 | 0.4324 | 1001.0 | 793.9 | |
| 0.00 | 1.52 | 0.00 | 0.84 | 19.21 | 53.37 | -11.90 | 26.52 | 0.4378 | 721.0 | 429.0 | |
| 0.00 | 1.16 | 0.00 | 0.69 | 27.10 | 52.46 | -12.81 | 21.06 | 0.5514 | 704.0 | 556.9 | |
| 0.00 | 1.70 | 0.00 | 1.01 | 25.93 | 49.12 | -16.15 | 26.85 | 0.5560 | 639.0 | 453.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
