SDO HMI 2011-05-05 06:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 75.72 | 285.94 | 40.45 | 153.03 | 16.49 | 48.04 | -8.95 | 23.13 | 0.3792 | -215.4 | -162.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-05 06:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.52 | 0.00 | 0.82 | 18.76 | 53.28 | -3.71 | 9.09 | 0.3896 | 835.0 | 618.9 | |
| 0.00 | 1.79 | 0.00 | 0.95 | 17.22 | 50.71 | -6.28 | 16.29 | 0.3743 | 343.0 | 305.9 | |
| 7.06 | 153.76 | 3.76 | 81.78 | 16.74 | 49.99 | -7.00 | 18.44 | 0.3703 | -867.0 | -539.7 | |
| 9.12 | -3.00 | 4.85 | -3.00 | 16.32 | 49.88 | -7.11 | 19.10 | 0.3645 | -1187.4 | 999999 | |
| 0.00 | 1.88 | 0.00 | 0.99 | 15.10 | 49.64 | -7.35 | 20.93 | 0.3472 | -1067.0 | -843.0 | |
| 5.72 | -3.00 | 3.04 | -3.00 | 15.90 | 49.55 | -7.44 | 20.34 | 0.3600 | -1070.9 | 999999 | |
| 24.05 | -3.00 | 12.80 | -3.00 | 16.36 | 49.43 | -7.56 | 20.17 | 0.3675 | -1067.3 | 999999 | |
| 0.00 | 1.43 | 0.00 | 0.76 | 15.04 | 49.26 | -7.73 | 21.97 | 0.3485 | -776.0 | -633.6 | |
| 0.00 | 1.34 | 0.00 | 0.74 | 21.78 | 48.95 | -8.04 | 16.78 | 0.4516 | 764.0 | 559.6 | |
| 0.00 | 1.43 | 0.00 | 0.76 | 15.43 | 49.09 | -7.90 | 21.99 | 0.3554 | -808.0 | -605.0 | |
| 0.00 | 1.07 | 0.00 | 0.57 | 15.75 | 49.05 | -7.94 | 21.75 | 0.3605 | -862.0 | -645.5 | |
| 8.67 | 23.51 | 4.63 | 12.56 | 16.46 | 48.83 | -8.16 | 21.54 | 0.3726 | -968.2 | -254.1 | |
| 0.36 | 3.04 | 0.19 | 1.62 | 16.56 | 48.34 | -8.65 | 22.57 | 0.3770 | -917.0 | -702.7 | |
| 1.97 | 3.13 | 1.05 | 1.66 | 15.69 | 48.22 | -8.77 | 23.82 | 0.3649 | -922.5 | -838.3 | |
| 0.00 | 0.98 | 0.00 | 0.54 | 19.43 | 47.91 | -9.08 | 20.74 | 0.4221 | -841.0 | -708.4 | |
| 0.00 | 2.41 | 0.00 | 1.29 | 16.66 | 48.02 | -8.97 | 23.22 | 0.3805 | -720.0 | -504.9 | |
| 1.16 | 2.86 | 0.62 | 1.53 | 16.02 | 47.99 | -9.00 | 24.01 | 0.3713 | -761.2 | -521.5 | |
| 0.89 | 5.36 | 0.48 | 2.86 | 15.82 | 47.96 | -9.03 | 24.29 | 0.3686 | -889.6 | -541.1 | |
| 0.00 | 1.16 | 0.00 | 0.62 | 16.99 | 47.59 | -9.40 | 23.84 | 0.3881 | -682.0 | -493.2 | |
| 1.25 | 4.29 | 0.67 | 2.30 | 16.16 | 46.99 | -10.00 | 26.15 | 0.3801 | 883.8 | 813.1 | |
| 0.00 | 3.31 | 0.00 | 1.79 | 17.97 | 46.70 | -10.29 | 24.71 | 0.4083 | -889.0 | -685.9 | |
| 0.00 | 0.98 | 0.00 | 0.53 | 17.00 | 46.43 | -10.56 | 26.37 | 0.3962 | 777.0 | 639.8 | |
| 0.00 | 1.07 | 0.00 | 0.58 | 17.17 | 46.23 | -10.76 | 26.61 | 0.4000 | -486.0 | -437.4 | |
| 3.22 | 20.38 | 1.74 | 11.00 | 16.66 | 45.10 | -11.89 | 29.58 | 0.4015 | 1083.1 | 686.7 | |
| 1.61 | -24.00 | 0.87 | -24.00 | 16.34 | 45.12 | -11.87 | 29.96 | 0.3969 | 816.1 | 999999 | |
| 0.00 | 3.04 | 0.00 | 1.65 | 16.86 | 44.70 | -12.29 | 30.14 | 0.4075 | 727.0 | 654.6 | |
| 0.00 | 1.52 | 0.00 | 0.83 | 17.32 | 44.44 | -12.55 | 30.07 | 0.4157 | 681.0 | 619.6 | |
| 0.00 | 0.89 | 0.00 | 0.48 | 15.74 | 44.48 | -12.51 | 32.10 | 0.3940 | 869.0 | 691.0 | |
| 0.00 | 1.43 | 0.00 | 0.78 | 16.77 | 44.38 | -12.61 | 30.90 | 0.4088 | 997.0 | 790.0 | |
| 10.64 | 11.89 | 5.75 | 6.43 | 16.19 | 44.29 | -12.70 | 31.85 | 0.4017 | 1081.8 | 739.4 | |
| 0.00 | 1.70 | 0.00 | 0.92 | 16.42 | 44.24 | -12.75 | 31.64 | 0.4052 | 273.0 | 500.2 | |
| 0.00 | 4.11 | 0.00 | 2.23 | 16.65 | 43.97 | -13.02 | 31.87 | 0.4106 | 979.0 | 904.7 | |
| 0.00 | 2.59 | 0.00 | 1.42 | 18.17 | 43.82 | -13.17 | 30.19 | 0.4322 | 782.0 | 678.4 | |
| 0.00 | 5.63 | 0.00 | 3.05 | 16.13 | 43.91 | -13.08 | 32.70 | 0.4042 | 1006.0 | 867.6 | |
| 0.00 | 1.43 | 0.00 | 0.77 | 15.56 | 43.88 | -13.11 | 33.57 | 0.3968 | 781.0 | 645.0 | |
| 0.00 | 0.89 | 0.00 | 0.49 | 16.65 | 43.64 | -13.35 | 32.50 | 0.4134 | 753.0 | 602.2 | |
| 0.00 | 1.07 | 0.00 | 0.58 | 15.85 | 43.70 | -13.29 | 33.51 | 0.4023 | 699.0 | 547.8 | |
| 0.00 | 3.49 | 0.00 | 1.91 | 17.56 | 43.58 | -13.41 | 31.42 | 0.4260 | 474.0 | 559.5 | |
| 0.00 | 0.89 | 0.00 | 0.49 | 17.33 | 43.56 | -13.43 | 31.75 | 0.4231 | 840.0 | 673.7 | |
| 0.00 | 3.04 | 0.00 | 1.67 | 17.69 | 43.40 | -13.59 | 31.58 | 0.4292 | 915.0 | 631.2 | |
| 0.00 | 0.98 | 0.00 | 0.53 | 16.53 | 43.49 | -13.50 | 32.96 | 0.4130 | 693.0 | 526.3 | |
| 0.00 | 1.97 | 0.00 | 1.08 | 17.89 | 43.26 | -13.73 | 31.60 | 0.4330 | 667.0 | 485.9 | |
| 0.00 | 1.61 | 0.00 | 0.89 | 18.44 | 41.53 | -15.46 | 33.94 | 0.4547 | 708.0 | 576.6 | |
| 0.00 | 1.07 | 0.00 | 0.58 | 14.99 | 41.49 | -15.50 | 38.96 | 0.4122 | 604.0 | 490.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
