SDO HMI 2011-05-05 12:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 47.00 | 326.87 | 25.26 | 175.78 | 17.93 | 61.15 | 7.44 | 341.49 | 0.3907 | -920.3 | -396.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-05 12:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 42.89 | 312.84 | 23.05 | 168.15 | 17.80 | 61.31 | 7.60 | 341.03 | 0.3893 | -1394.5 | -420.0 | |
| 4.11 | -1.00 | 2.21 | -1.00 | 18.19 | 60.87 | 7.17 | 342.35 | 0.3930 | -985.7 | 999999 | |
| 0.00 | 1.52 | 0.00 | 0.82 | 19.30 | 60.73 | 7.03 | 343.54 | 0.4093 | -487.0 | -434.6 | |
| 0.00 | 1.88 | 0.00 | 1.06 | 24.25 | 59.94 | 6.24 | 348.07 | 0.4813 | -794.0 | -652.5 | |
| 0.00 | 2.68 | 0.00 | 1.45 | 19.32 | 59.47 | 5.77 | 346.37 | 0.4044 | -777.0 | -539.7 | |
| 0.00 | 0.98 | 0.00 | 0.53 | 19.16 | 59.30 | 5.60 | 346.65 | 0.4012 | -755.0 | -526.2 | |
| 0.00 | 1.88 | 0.00 | 1.00 | 17.77 | 57.89 | 4.19 | 349.26 | 0.3747 | 681.0 | 621.7 | |
| 0.00 | 0.71 | 0.00 | 0.38 | 17.84 | 57.51 | 3.81 | 350.24 | 0.3746 | 818.0 | 730.5 | |
| 0.00 | 1.61 | 0.00 | 0.86 | 18.46 | 57.43 | 3.73 | 350.73 | 0.3843 | 902.0 | 690.4 | |
| 0.00 | 0.89 | 0.00 | 0.48 | 17.61 | 57.28 | 3.58 | 350.71 | 0.3703 | 863.0 | 673.8 | |
| 0.00 | 0.63 | 0.00 | 0.35 | 23.96 | 55.58 | 1.88 | 356.31 | 0.4676 | 665.0 | 594.7 | |
| 0.00 | 1.25 | 0.00 | 0.70 | 23.38 | 55.57 | 1.87 | 356.24 | 0.4587 | 757.0 | 614.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
