SDO HMI 2011-05-06 07:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 43.11 | 291.29 | 24.14 | 162.97 | 17.96 | 60.88 | 17.66 | 321.71 | 0.4677 | -963.5 | -391.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-06 07:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 40.78 | 283.42 | 22.84 | 158.65 | 17.92 | 61.05 | 17.83 | 321.38 | 0.4687 | -1345.0 | -424.4 | |
| 2.33 | -1.00 | 1.30 | -1.00 | 18.23 | 60.42 | 17.20 | 322.81 | 0.4664 | -812.7 | 999999 | |
| 0.00 | 1.25 | 0.00 | 0.69 | 18.38 | 57.95 | 14.72 | 327.13 | 0.4462 | 698.0 | 540.1 | |
| 0.00 | 0.98 | 0.00 | 0.54 | 17.79 | 57.76 | 14.54 | 326.68 | 0.4370 | 777.0 | 578.8 | |
| 0.00 | 2.33 | 0.00 | 1.28 | 18.84 | 56.08 | 12.86 | 331.08 | 0.4372 | 699.0 | 622.2 | |
| 0.00 | 1.34 | 0.00 | 0.74 | 19.26 | 55.85 | 12.63 | 331.99 | 0.4412 | 586.0 | 568.5 | |
| 0.00 | 1.97 | 0.00 | 1.07 | 18.65 | 53.88 | 10.66 | 335.16 | 0.4188 | 941.0 | 841.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
