SDO HMI 2011-05-06 09:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 42.04 | 302.77 | 23.66 | 170.42 | 18.05 | 60.63 | 18.50 | 320.60 | 0.4775 | -649.8 | -356.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-06 09:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.07 | 0.00 | 0.61 | 17.75 | 62.15 | 20.03 | 317.91 | 0.4885 | 4.0 | 27.2 | |
| 39.44 | 285.98 | 22.23 | 161.10 | 17.92 | 61.03 | 18.90 | 319.76 | 0.4790 | -1334.6 | -412.3 | |
| 0.54 | -2.00 | 0.30 | -2.00 | 18.26 | 60.46 | 18.33 | 321.09 | 0.4775 | -739.0 | 999999 | |
| 0.00 | 0.98 | 0.00 | 0.54 | 17.75 | 57.75 | 15.62 | 324.73 | 0.4459 | 763.0 | 628.5 | |
| 0.00 | 1.16 | 0.00 | 0.64 | 18.21 | 57.62 | 15.50 | 325.55 | 0.4505 | 822.0 | 570.9 | |
| 0.00 | 1.52 | 0.00 | 0.84 | 18.90 | 56.13 | 14.01 | 329.03 | 0.4469 | 793.0 | 723.7 | |
| 0.00 | 1.25 | 0.00 | 0.69 | 19.22 | 55.93 | 13.80 | 329.79 | 0.4495 | 731.0 | 442.9 | |
| 0.00 | 1.43 | 0.00 | 0.82 | 23.56 | 55.88 | 13.75 | 334.43 | 0.5070 | 800.0 | 671.7 | |
| 0.00 | 1.25 | 0.00 | 0.72 | 24.72 | 55.15 | 13.03 | 336.62 | 0.5179 | 580.0 | 441.0 | |
| 2.06 | 2.77 | 1.13 | 1.52 | 18.67 | 53.85 | 11.73 | 333.03 | 0.4264 | 880.0 | 799.0 | |
| 0.00 | 1.16 | 0.00 | 0.64 | 21.70 | 49.93 | 7.80 | 343.57 | 0.4476 | 863.0 | 637.0 | |
| 0.00 | 2.68 | 0.00 | 1.46 | 19.77 | 49.76 | 7.63 | 342.52 | 0.4178 | 934.0 | 681.7 | |
| 0.00 | 1.52 | 0.00 | 0.84 | 21.60 | 49.39 | 7.27 | 344.56 | 0.4437 | 821.0 | 618.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
