SDO HMI 2011-05-07 20:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 34.25 | 197.46 | 23.10 | 134.16 | 18.11 | 60.72 | 37.88 | 301.45 | 0.6861 | -733.1 | -354.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-07 20:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.98 | 0.00 | 0.72 | 23.05 | 63.25 | 40.41 | 306.02 | 0.7398 | -468.0 | -331.9 | |
| 28.80 | 188.70 | 19.63 | 128.64 | 17.98 | 61.06 | 38.22 | 301.02 | 0.6890 | -1074.6 | -376.0 | |
| 1.70 | -2.00 | 1.16 | -2.00 | 18.62 | 60.94 | 38.10 | 301.93 | 0.6913 | -463.9 | 999999 | |
| 0.00 | 1.34 | 0.00 | 0.85 | 21.02 | 52.85 | 30.01 | 311.13 | 0.6220 | 609.0 | 450.0 | |
| 2.41 | 3.67 | 1.49 | 2.26 | 19.72 | 51.43 | 28.59 | 310.71 | 0.5964 | 740.4 | 672.2 | |
| 0.00 | 1.07 | 0.00 | 0.66 | 19.83 | 50.64 | 27.80 | 311.60 | 0.5890 | 694.0 | 522.2 | |
| 1.34 | 1.70 | 0.82 | 1.03 | 19.37 | 50.52 | 27.68 | 311.09 | 0.5837 | 683.1 | 735.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
