SDO HMI 2011-05-07 23:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.08 | 198.17 | 24.19 | 137.81 | 18.10 | 60.75 | 39.57 | 300.42 | 0.7041 | -723.0 | -330.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-07 23:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 29.26 | 189.49 | 20.43 | 132.31 | 18.00 | 61.10 | 39.92 | 300.04 | 0.7073 | -977.4 | -354.1 | |
| 1.79 | -1.00 | 1.25 | -1.00 | 18.60 | 60.89 | 39.71 | 300.94 | 0.7083 | -446.0 | 999999 | |
| 0.00 | 2.06 | 0.00 | 1.37 | 19.82 | 56.79 | 35.62 | 305.10 | 0.6719 | 624.0 | 514.2 | |
| 2.51 | 3.85 | 1.57 | 2.41 | 19.79 | 51.41 | 30.23 | 309.29 | 0.6144 | 663.6 | 552.5 | |
| 1.52 | 2.77 | 0.94 | 1.72 | 19.25 | 50.67 | 29.49 | 309.21 | 0.6020 | 687.6 | 655.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
