SDO HMI 2011-05-08 01:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 64.34 | 227.71 | 39.15 | 139.60 | 16.72 | 50.15 | 30.07 | 305.24 | 0.5891 | -285.1 | -317.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-08 01:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.98 | 0.00 | 0.66 | 19.56 | 56.10 | 36.03 | 304.47 | 0.6746 | 579.0 | 520.6 | |
| 0.00 | 1.52 | 0.00 | 1.01 | 19.68 | 55.11 | 35.03 | 305.33 | 0.6648 | 570.0 | 416.5 | |
| 4.92 | 99.96 | 3.08 | 62.21 | 16.63 | 52.29 | 32.21 | 303.25 | 0.6130 | -812.9 | -445.7 | |
| 0.00 | 0.98 | 0.00 | 0.62 | 17.56 | 52.36 | 32.29 | 304.52 | 0.6203 | -415.0 | -292.6 | |
| 19.24 | -3.00 | 11.93 | -3.00 | 16.54 | 51.53 | 31.45 | 303.72 | 0.6036 | -897.3 | 999999 | |
| 0.00 | 6.09 | 0.00 | 3.79 | 17.09 | 51.63 | 31.56 | 304.42 | 0.6087 | -283.0 | -176.3 | |
| 2.24 | 5.01 | 1.37 | 3.07 | 16.04 | 50.92 | 30.85 | 303.48 | 0.5930 | -834.4 | -661.2 | |
| 0.00 | 2.06 | 0.00 | 1.26 | 16.42 | 50.77 | 30.69 | 304.16 | 0.5939 | -971.0 | -784.0 | |
| 3.31 | 35.35 | 2.04 | 21.68 | 16.64 | 50.77 | 30.70 | 304.48 | 0.5956 | -762.3 | -369.5 | |
| 2.15 | 15.75 | 1.31 | 9.60 | 15.80 | 50.59 | 30.51 | 303.40 | 0.5874 | -690.6 | -587.0 | |
| 0.00 | 1.43 | 0.00 | 0.88 | 16.15 | 50.61 | 30.54 | 303.91 | 0.5902 | -903.0 | -729.7 | |
| 0.00 | 1.25 | 0.00 | 0.76 | 14.99 | 50.31 | 30.24 | 302.42 | 0.5785 | 521.0 | 321.2 | |
| 8.05 | -10.00 | 4.90 | -10.00 | 15.79 | 50.26 | 30.18 | 303.66 | 0.5835 | -975.0 | 999999 | |
| 0.00 | 1.43 | 0.00 | 0.87 | 16.11 | 50.31 | 30.24 | 304.09 | 0.5864 | -855.0 | -555.9 | |
| 4.30 | -9.00 | 2.63 | -9.00 | 16.59 | 50.32 | 30.25 | 304.79 | 0.5900 | -783.2 | 999999 | |
| 3.85 | -9.00 | 2.35 | -9.00 | 16.37 | 50.28 | 30.21 | 304.49 | 0.5879 | -907.3 | 999999 | |
| 1.25 | 2.33 | 0.76 | 1.41 | 16.07 | 49.83 | 29.76 | 304.43 | 0.5804 | -788.1 | -699.8 | |
| 0.00 | 1.25 | 0.00 | 0.77 | 17.91 | 50.05 | 29.97 | 306.91 | 0.5968 | -629.0 | -454.2 | |
| 0.00 | 1.07 | 0.00 | 0.65 | 16.06 | 49.58 | 29.50 | 304.64 | 0.5774 | -630.0 | -536.5 | |
| 0.00 | 0.98 | 0.00 | 0.60 | 16.48 | 49.61 | 29.53 | 305.23 | 0.5809 | -550.0 | -390.5 | |
| 0.00 | 3.49 | 0.00 | 2.10 | 16.07 | 49.11 | 29.03 | 305.08 | 0.5720 | -649.0 | -669.4 | |
| 0.98 | 2.06 | 0.61 | 1.27 | 19.57 | 49.01 | 28.93 | 310.15 | 0.5986 | -411.8 | -419.8 | |
| 0.00 | 1.43 | 0.00 | 0.89 | 19.87 | 49.07 | 28.99 | 310.50 | 0.6017 | -466.0 | -348.7 | |
| 0.98 | 3.31 | 0.61 | 2.04 | 19.96 | 48.87 | 28.79 | 310.81 | 0.6003 | -514.9 | -640.4 | |
| 0.00 | 3.85 | 0.00 | 2.37 | 19.60 | 48.72 | 28.64 | 310.45 | 0.5957 | -844.0 | -731.0 | |
| 0.00 | 1.43 | 0.00 | 0.88 | 20.12 | 48.71 | 28.64 | 311.17 | 0.6000 | -492.0 | -397.5 | |
| 0.00 | 1.16 | 0.00 | 0.69 | 15.87 | 47.72 | 27.64 | 306.05 | 0.5541 | 466.0 | 359.2 | |
| 0.00 | 2.06 | 0.00 | 1.23 | 17.31 | 47.26 | 27.19 | 308.63 | 0.5605 | 250.0 | 236.3 | |
| 0.00 | 1.16 | 0.00 | 0.70 | 18.76 | 47.08 | 27.00 | 310.90 | 0.5709 | -656.0 | -510.3 | |
| 1.88 | 2.24 | 1.11 | 1.32 | 16.47 | 46.25 | 26.17 | 308.41 | 0.5419 | 662.3 | 579.5 | |
| 0.00 | 0.89 | 0.00 | 0.52 | 16.34 | 45.98 | 25.91 | 308.48 | 0.5377 | 576.0 | 477.1 | |
| 0.00 | 1.52 | 0.00 | 0.89 | 16.59 | 45.92 | 25.84 | 308.93 | 0.5391 | 698.0 | 572.6 | |
| 0.00 | 3.04 | 0.00 | 1.78 | 17.43 | 44.74 | 24.67 | 311.46 | 0.5334 | 597.0 | 559.3 | |
| 0.00 | 1.70 | 0.00 | 0.99 | 16.81 | 44.45 | 24.37 | 310.86 | 0.5243 | 708.0 | 525.8 | |
| 0.00 | 1.16 | 0.00 | 0.67 | 15.42 | 44.13 | 24.05 | 309.07 | 0.5081 | 749.0 | 602.5 | |
| 0.00 | 1.61 | 0.00 | 0.93 | 16.51 | 44.06 | 23.98 | 310.85 | 0.5172 | 626.0 | 453.7 | |
| 11.19 | 12.98 | 6.45 | 7.48 | 16.22 | 43.88 | 23.81 | 310.60 | 0.5125 | 955.1 | 793.5 | |
| 0.00 | 1.79 | 0.00 | 1.05 | 18.35 | 43.76 | 23.68 | 313.91 | 0.5313 | 617.0 | 515.0 | |
| 0.00 | 1.25 | 0.00 | 0.73 | 18.18 | 43.67 | 23.59 | 313.78 | 0.5287 | 812.0 | 669.6 | |
| 0.00 | 0.89 | 0.00 | 0.51 | 14.92 | 43.14 | 23.07 | 309.40 | 0.4919 | 753.0 | 624.9 | |
| 0.00 | 1.25 | 0.00 | 0.72 | 17.23 | 43.29 | 23.22 | 312.83 | 0.5155 | 729.0 | 663.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
