SDO HMI 2011-05-26 16:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 41.81 | 121.48 | 22.78 | 65.93 | -15.73 | 114.20 | -19.56 | 127.89 | 0.4095 | -76.3 | -25.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-26 16:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.43 | 27.67 | 1.30 | 14.77 | -15.43 | 117.05 | -16.70 | 131.38 | 0.3708 | 1055.7 | 741.6 | |
| 5.95 | -1.00 | 3.18 | -1.00 | -15.68 | 116.83 | -16.92 | 131.54 | 0.3760 | 1023.3 | 999999 | |
| 0.00 | 1.53 | 0.00 | 0.82 | -15.99 | 116.64 | -17.12 | 131.88 | 0.3816 | 778.0 | 520.6 | |
| 0.00 | 1.17 | 0.00 | 0.63 | -15.93 | 116.44 | -17.31 | 131.44 | 0.3832 | 715.0 | 522.0 | |
| 0.00 | 3.79 | 0.00 | 2.04 | -16.90 | 116.25 | -17.50 | 133.08 | 0.3955 | 762.0 | 559.3 | |
| 2.79 | 5.86 | 1.50 | 3.14 | -14.61 | 115.24 | -18.51 | 126.85 | 0.3856 | 910.4 | 712.9 | |
| 0.00 | 0.81 | 0.00 | 0.44 | -15.67 | 115.04 | -18.71 | 128.80 | 0.3980 | 800.0 | 686.3 | |
| 0.00 | 1.35 | 0.00 | 0.73 | -14.04 | 114.86 | -18.90 | 125.10 | 0.3856 | 944.0 | 705.7 | |
| 0.00 | 1.17 | 0.00 | 0.63 | -15.85 | 114.69 | -19.06 | 128.68 | 0.4042 | 641.0 | 485.9 | |
| 0.00 | 0.81 | 0.00 | 0.44 | -16.80 | 114.56 | -19.19 | 130.35 | 0.4147 | 741.0 | 608.2 | |
| 0.00 | 1.17 | 0.00 | 0.63 | -15.41 | 114.67 | -19.09 | 127.75 | 0.4004 | 828.0 | 716.6 | |
| 0.72 | 2.16 | 0.39 | 1.17 | -16.32 | 114.47 | -19.28 | 129.31 | 0.4112 | 978.1 | 810.0 | |
| 0.00 | 0.99 | 0.00 | 0.53 | -14.63 | 114.61 | -19.15 | 126.03 | 0.3941 | -590.0 | -509.6 | |
| 0.00 | 1.26 | 0.00 | 0.68 | -14.04 | 114.56 | -19.19 | 124.69 | 0.3895 | 742.0 | 629.9 | |
| 0.00 | 2.07 | 0.00 | 1.12 | -14.54 | 114.41 | -19.34 | 125.57 | 0.3958 | 629.0 | 502.1 | |
| 0.00 | 1.71 | 0.00 | 0.92 | -14.19 | 114.38 | -19.37 | 124.79 | 0.3933 | 824.0 | 670.9 | |
| 0.00 | 1.08 | 0.00 | 0.59 | -14.88 | 113.85 | -19.90 | 125.55 | 0.4061 | 514.0 | 338.0 | |
| 0.00 | 1.26 | 0.00 | 0.69 | -16.09 | 113.25 | -20.50 | 127.24 | 0.4244 | -1082.0 | -976.0 | |
| 4.06 | 5.14 | 2.22 | 2.81 | -16.41 | 113.15 | -20.60 | 127.72 | 0.4285 | -832.5 | -762.1 | |
| 2.34 | 37.32 | 1.28 | 20.41 | -15.56 | 113.21 | -20.54 | 126.13 | 0.4203 | -1016.5 | -826.0 | |
| 0.00 | 2.52 | 0.00 | 1.37 | -15.15 | 113.22 | -20.53 | 125.32 | 0.4167 | -1041.0 | -834.9 | |
| 6.40 | -20.00 | 3.50 | -20.00 | -15.93 | 113.00 | -20.75 | 126.61 | 0.4262 | -1062.2 | 999999 | |
| 2.70 | -20.00 | 1.48 | -20.00 | -15.46 | 112.92 | -20.84 | 125.57 | 0.4232 | -1039.8 | 999999 | |
| 1.26 | -20.00 | 0.69 | -20.00 | -15.65 | 112.83 | -20.92 | 125.84 | 0.4259 | -1261.5 | 999999 | |
| 11.27 | 16.41 | 6.20 | 9.02 | -16.31 | 112.52 | -21.23 | 126.74 | 0.4356 | -851.0 | -665.6 | |
| 1.89 | -20.00 | 1.04 | -20.00 | -15.84 | 112.50 | -21.25 | 125.81 | 0.4317 | -741.4 | 999999 | |
| 0.00 | 1.71 | 0.00 | 0.95 | -16.17 | 111.07 | -22.68 | 124.79 | 0.4529 | -756.0 | -658.2 | |
| 0.00 | 2.52 | 0.00 | 1.40 | -16.26 | 110.85 | -22.90 | 124.73 | 0.4564 | -590.0 | -556.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
