SDO HMI 2011-05-30 00:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.81 | 49.39 | 17.07 | 57.84 | -18.53 | 25.85 | -63.77 | 110.07 | 0.9072 | 425.8 | 132.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-30 00:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 11.29 | 22.39 | 12.89 | 25.64 | -18.24 | 26.41 | -63.21 | 109.84 | 0.9030 | 556.6 | 79.8 | |
| 0.00 | 1.72 | 0.00 | 2.03 | -19.32 | 25.59 | -64.03 | 110.90 | 0.9098 | 303.0 | 333.2 | |
| 0.00 | 0.99 | 0.00 | 1.16 | -18.62 | 25.80 | -63.83 | 110.16 | 0.9077 | 461.0 | 479.4 | |
| 1.35 | 20.95 | 1.61 | 25.01 | -19.00 | 25.38 | -64.24 | 110.51 | 0.9110 | 624.7 | 235.1 | |
| 2.17 | -4.00 | 2.57 | -4.00 | -18.61 | 25.43 | -64.19 | 110.10 | 0.9102 | 355.9 | 999999 | |
| 0.00 | 1.99 | 0.00 | 2.35 | -18.13 | 25.39 | -64.23 | 109.57 | 0.9100 | -563.0 | -545.2 | |
| 0.00 | 1.35 | 0.00 | 1.65 | -18.93 | 24.68 | -64.94 | 110.33 | 0.9156 | -325.0 | -284.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
