SDO HMI 2011-05-30 02:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 18.78 | 123.35 | 24.67 | 163.97 | 16.68 | 21.92 | -66.60 | 71.55 | 0.9283 | -650.5 | -107.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-30 02:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.90 | 121.91 | 1.18 | 161.46 | 17.48 | 22.34 | -66.18 | 70.64 | 0.9265 | -479.2 | -113.5 | |
| 17.88 | -1.00 | 23.49 | -1.00 | 16.62 | 21.99 | -66.53 | 71.61 | 0.9279 | -737.6 | 999999 | |
| 0.00 | 0.63 | 0.00 | 0.99 | 16.97 | 18.02 | -70.50 | 71.76 | 0.9506 | 320.0 | 287.1 | |
| 0.00 | 0.81 | 0.00 | 1.52 | 18.59 | 15.15 | -73.37 | 70.41 | 0.9651 | 222.0 | 213.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
