SDO HMI 2011-05-30 09:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.36 | 11.01 | 0.21 | 6.57 | -15.53 | 115.26 | 30.58 | 242.48 | 0.5542 | -185.5 | 31.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-30 09:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.63 | 0.00 | 1.00 | -16.37 | 118.06 | 33.38 | 242.97 | 0.5948 | 580.0 | 473.9 | |
| 0.00 | 2.80 | 0.00 | 1.71 | -16.19 | 117.35 | 32.66 | 242.83 | 0.5848 | 576.0 | 495.5 | |
| 0.00 | 1.54 | 0.00 | 0.93 | -16.10 | 117.03 | 32.35 | 242.77 | 0.5803 | 669.0 | 523.4 | |
| 0.00 | 1.17 | 0.00 | 0.68 | -11.53 | 113.59 | 28.91 | 248.51 | 0.5110 | -739.0 | -532.2 | |
| 0.00 | 1.26 | 0.00 | 0.74 | -15.65 | 113.32 | 28.63 | 240.93 | 0.5300 | -729.0 | -587.5 | |
| 0.36 | 1.26 | 0.21 | 0.74 | -15.90 | 112.89 | 28.21 | 240.16 | 0.5261 | -781.2 | -643.3 | |
| 0.00 | 1.35 | 0.00 | 0.77 | -15.32 | 110.46 | 25.78 | 239.14 | 0.4906 | -749.0 | -618.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
