SDO HMI 2011-05-30 09:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 18.97 | 95.07 | 10.93 | 54.88 | 16.81 | 59.14 | -25.54 | 53.73 | 0.5139 | -941.3 | -454.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-30 09:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.26 | 0.00 | 0.70 | 15.41 | 64.42 | -20.26 | 50.02 | 0.4374 | -679.0 | -502.6 | |
| 0.00 | 1.17 | 0.00 | 0.67 | 17.37 | 60.87 | -23.81 | 50.98 | 0.4979 | 651.0 | 414.8 | |
| 1.54 | 88.77 | 0.89 | 51.18 | 17.03 | 59.17 | -25.52 | 53.35 | 0.5154 | -871.4 | -464.3 | |
| 17.43 | -3.00 | 10.04 | -3.00 | 16.72 | 59.18 | -25.50 | 53.86 | 0.5127 | -1208.3 | 999999 | |
| 0.00 | 1.26 | 0.00 | 0.75 | 19.01 | 57.56 | -27.12 | 51.83 | 0.5504 | -741.0 | -544.2 | |
| 0.00 | 1.26 | 0.00 | 0.75 | 18.14 | 57.10 | -27.58 | 53.59 | 0.5488 | -611.0 | -477.6 | |
| 0.00 | 1.35 | 0.00 | 0.83 | 18.65 | 54.37 | -30.32 | 55.19 | 0.5847 | -708.0 | -538.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
