SDO HMI 2011-05-30 13:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 6.76 | 0.00 | 4.14 | -16.21 | 115.17 | 32.69 | 242.70 | 0.5848 | 98.8 | 171.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-30 13:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.35 | 0.00 | 1.47 | -16.54 | 117.08 | 34.60 | 243.41 | 0.6109 | 611.0 | 537.8 | |
| 0.00 | 1.17 | 0.00 | 0.73 | -15.94 | 116.92 | 34.44 | 244.24 | 0.6059 | 771.0 | 641.3 | |
| 0.00 | 0.81 | 0.00 | 0.51 | -17.24 | 116.61 | 34.12 | 242.06 | 0.6087 | 621.0 | 506.3 | |
| 0.00 | 1.26 | 0.00 | 0.75 | -15.94 | 112.98 | 30.49 | 241.79 | 0.5559 | -768.0 | -567.9 | |
| 0.00 | 1.17 | 0.00 | 0.68 | -15.33 | 110.49 | 28.01 | 240.99 | 0.5199 | -741.0 | -554.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
