SDO HMI 2011-05-30 14:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 148.23 | 695.99 | 110.30 | 516.52 | -20.73 | 37.01 | -44.92 | 117.53 | 0.7459 | 274.9 | 135.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-30 14:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.62 | 0.00 | 1.85 | -21.38 | 40.35 | -41.58 | 119.79 | 0.7144 | 501.0 | 398.8 | |
| 50.82 | 395.85 | 36.05 | 281.50 | -19.75 | 39.37 | -42.56 | 117.20 | 0.7181 | 1096.3 | 402.6 | |
| 12.55 | 74.30 | 9.21 | 54.90 | -22.14 | 38.19 | -43.74 | 119.79 | 0.7402 | 802.3 | 59.5 | |
| 12.37 | -2.00 | 8.87 | -2.00 | -20.17 | 38.87 | -43.06 | 117.54 | 0.7251 | 813.1 | 999999 | |
| 5.06 | -2.00 | 3.62 | -2.00 | -19.65 | 38.74 | -43.19 | 116.80 | 0.7245 | 705.5 | 999999 | |
| 1.81 | -2.00 | 1.30 | -2.00 | -19.97 | 38.54 | -43.39 | 117.14 | 0.7278 | 483.6 | 999999 | |
| 0.36 | -2.00 | 0.26 | -2.00 | -18.98 | 38.87 | -43.06 | 115.97 | 0.7205 | 215.2 | 999999 | |
| 8.12 | -2.00 | 5.88 | -2.00 | -20.20 | 38.33 | -43.60 | 117.34 | 0.7310 | 648.8 | 999999 | |
| 0.00 | 2.89 | 0.00 | 2.12 | -21.46 | 37.82 | -44.11 | 118.75 | 0.7412 | 661.0 | 578.6 | |
| 5.15 | -2.00 | 3.70 | -2.00 | -19.55 | 38.42 | -43.52 | 116.54 | 0.7276 | 485.9 | 999999 | |
| 0.00 | 0.81 | 0.00 | 0.61 | -23.05 | 37.03 | -44.90 | 120.43 | 0.7555 | -633.0 | -497.6 | |
| 3.07 | -2.00 | 2.19 | -2.00 | -18.75 | 38.59 | -43.34 | 115.56 | 0.7227 | 512.9 | 999999 | |
| 2.98 | -2.00 | 2.18 | -2.00 | -20.84 | 37.73 | -44.20 | 117.92 | 0.7397 | 553.0 | 999999 | |
| 0.00 | 1.08 | 0.00 | 0.80 | -21.49 | 37.49 | -44.44 | 118.65 | 0.7447 | 353.0 | 246.6 | |
| 0.99 | -2.00 | 0.72 | -2.00 | -20.10 | 37.96 | -43.97 | 117.06 | 0.7345 | 181.2 | 999999 | |
| 0.00 | 1.90 | 0.00 | 1.41 | -21.81 | 37.27 | -44.66 | 118.97 | 0.7482 | -236.0 | -179.0 | |
| 0.00 | 1.08 | 0.00 | 0.79 | -20.22 | 37.73 | -44.20 | 117.13 | 0.7374 | 390.0 | 217.5 | |
| 0.00 | 0.81 | 0.00 | 0.59 | -20.09 | 37.78 | -44.15 | 116.98 | 0.7364 | 152.0 | 204.7 | |
| 0.00 | 1.08 | 0.00 | 0.80 | -20.51 | 37.58 | -44.35 | 117.44 | 0.7400 | 432.0 | 357.4 | |
| 0.00 | 1.53 | 0.00 | 1.15 | -22.43 | 36.83 | -45.10 | 119.56 | 0.7550 | -599.0 | -510.3 | |
| 0.00 | 1.17 | 0.00 | 0.85 | -19.19 | 38.00 | -43.93 | 115.90 | 0.7307 | 391.0 | 347.9 | |
| 0.00 | 0.72 | 0.00 | 0.53 | -21.03 | 37.34 | -44.59 | 118.01 | 0.7445 | 319.0 | 232.8 | |
| 0.00 | 0.90 | 0.00 | 0.65 | -19.10 | 37.85 | -44.08 | 115.72 | 0.7319 | 243.0 | 247.6 | |
| 0.00 | 0.99 | 0.00 | 0.72 | -18.14 | 37.85 | -44.08 | 114.46 | 0.7285 | 452.0 | 427.5 | |
| 0.90 | 2.35 | 0.68 | 1.75 | -21.22 | 36.71 | -45.22 | 117.99 | 0.7516 | -742.1 | -596.5 | |
| 0.00 | 1.62 | 0.00 | 1.18 | -18.45 | 37.62 | -44.31 | 114.79 | 0.7322 | 584.0 | 368.6 | |
| 0.00 | 0.99 | 0.00 | 0.74 | -20.89 | 36.52 | -45.41 | 117.50 | 0.7524 | -627.0 | -485.5 | |
| 0.00 | 1.62 | 0.00 | 1.23 | -20.89 | 36.10 | -45.83 | 117.33 | 0.7567 | -472.0 | -473.2 | |
| 0.00 | 1.53 | 0.00 | 1.19 | -22.51 | 35.18 | -46.75 | 119.00 | 0.7716 | -597.0 | -524.8 | |
| 0.00 | 0.99 | 0.00 | 0.75 | -20.69 | 35.94 | -45.99 | 117.03 | 0.7576 | -579.0 | -467.9 | |
| 1.35 | 1.44 | 1.03 | 1.10 | -21.01 | 35.77 | -46.17 | 117.37 | 0.7605 | -691.7 | -809.0 | |
| 4.51 | 67.71 | 3.45 | 52.00 | -20.98 | 35.45 | -46.48 | 117.20 | 0.7636 | -752.2 | -456.0 | |
| 0.00 | 1.72 | 0.00 | 1.34 | -22.01 | 34.72 | -47.21 | 118.22 | 0.7743 | -628.0 | -466.8 | |
| 1.72 | -32.00 | 1.32 | -32.00 | -20.88 | 35.16 | -46.78 | 116.97 | 0.7662 | -793.4 | 999999 | |
| 1.53 | -32.00 | 1.18 | -32.00 | -21.17 | 34.99 | -46.94 | 117.27 | 0.7688 | 268.1 | 999999 | |
| 5.15 | -32.00 | 3.98 | -32.00 | -20.71 | 34.70 | -47.23 | 116.59 | 0.7702 | -734.4 | 999999 | |
| 0.00 | 1.81 | 0.00 | 1.38 | -19.94 | 34.96 | -46.97 | 115.72 | 0.7650 | -185.0 | -185.6 | |
| 0.00 | 9.03 | 0.00 | 6.97 | -20.06 | 34.58 | -47.36 | 115.74 | 0.7693 | 14.0 | -2.8 | |
| 3.79 | 15.17 | 3.09 | 12.35 | -23.11 | 32.82 | -49.11 | 118.86 | 0.7961 | -855.4 | -564.9 | |
| 0.00 | 0.45 | 0.00 | 0.35 | -20.48 | 33.97 | -47.96 | 116.05 | 0.7767 | -427.0 | -318.4 | |
| 2.98 | 4.97 | 2.41 | 4.01 | -22.39 | 32.97 | -48.96 | 118.04 | 0.7924 | -749.5 | -463.7 | |
| 0.00 | 1.81 | 0.00 | 1.49 | -23.47 | 32.34 | -49.60 | 119.11 | 0.8017 | -506.0 | -414.5 | |
| 0.00 | 1.26 | 0.00 | 0.99 | -20.38 | 33.67 | -48.26 | 115.82 | 0.7793 | -435.0 | -344.0 | |
| 0.00 | 1.35 | 0.00 | 1.13 | -23.89 | 31.91 | -50.02 | 119.47 | 0.8070 | -181.0 | -265.5 | |
| 0.00 | 2.44 | 0.00 | 1.98 | -22.32 | 32.60 | -49.33 | 117.83 | 0.7956 | -765.0 | -671.7 | |
| 0.00 | 1.90 | 0.00 | 1.56 | -22.51 | 32.25 | -49.68 | 117.94 | 0.7995 | -521.0 | -454.8 | |
| 1.35 | 3.52 | 1.08 | 2.82 | -20.53 | 32.97 | -48.97 | 115.78 | 0.7867 | 281.3 | -95.9 | |
| 7.40 | 50.82 | 6.21 | 42.98 | -23.16 | 31.41 | -50.52 | 118.43 | 0.8092 | -702.1 | -7.5 | |
| 3.79 | -48.00 | 3.18 | -48.00 | -22.86 | 31.35 | -50.58 | 118.06 | 0.8088 | -710.8 | 999999 | |
| 0.00 | 3.16 | 0.00 | 2.58 | -21.14 | 32.09 | -49.84 | 116.23 | 0.7969 | -672.0 | -604.9 | |
| 1.90 | -48.00 | 1.60 | -48.00 | -22.93 | 30.95 | -50.98 | 118.00 | 0.8126 | -274.0 | 999999 | |
| 3.16 | 26.45 | 2.60 | 21.88 | -21.20 | 31.76 | -50.17 | 116.20 | 0.8002 | -578.8 | -197.4 | |
| 0.45 | -52.00 | 0.37 | -52.00 | -21.78 | 31.43 | -50.50 | 116.80 | 0.8050 | -544.6 | 999999 | |
| 3.16 | -52.00 | 2.62 | -52.00 | -21.52 | 31.50 | -50.43 | 116.51 | 0.8035 | -521.6 | 999999 | |
| 1.81 | 2.98 | 1.52 | 2.51 | -22.37 | 30.98 | -50.95 | 117.35 | 0.8108 | -430.5 | -457.8 | |
| 0.00 | 1.17 | 0.00 | 0.99 | -22.56 | 30.83 | -51.11 | 117.53 | 0.8127 | -292.0 | -194.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
