SDO HMI 2011-05-30 17:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.38 | 173.20 | 36.14 | 179.46 | -19.83 | 20.58 | -59.69 | 112.22 | 0.8790 | 223.4 | 74.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-30 17:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.63 | 0.00 | 0.59 | -19.19 | 23.91 | -56.36 | 112.18 | 0.8512 | -580.0 | -531.9 | |
| 4.15 | 19.14 | 3.88 | 17.92 | -17.59 | 23.73 | -56.54 | 110.29 | 0.8500 | -688.2 | -424.5 | |
| 0.00 | 1.53 | 0.00 | 1.50 | -19.65 | 22.52 | -57.75 | 112.42 | 0.8636 | -582.0 | -470.9 | |
| 1.44 | -2.00 | 1.36 | -2.00 | -17.58 | 23.38 | -56.89 | 110.22 | 0.8530 | -265.7 | 999999 | |
| 0.00 | 1.44 | 0.00 | 1.41 | -18.98 | 22.41 | -57.86 | 111.63 | 0.8633 | -731.0 | -569.9 | |
| 0.00 | 0.81 | 0.00 | 0.79 | -17.66 | 22.20 | -58.07 | 110.08 | 0.8630 | -424.0 | -336.0 | |
| 3.88 | 15.16 | 3.83 | 15.01 | -18.30 | 21.80 | -58.47 | 110.73 | 0.8672 | -632.2 | -304.9 | |
| 2.26 | -7.00 | 2.23 | -7.00 | -18.04 | 21.76 | -58.51 | 110.43 | 0.8672 | -415.4 | 999999 | |
| 21.57 | 131.06 | 22.74 | 138.64 | -20.34 | 20.01 | -60.26 | 112.69 | 0.8843 | 784.4 | 184.3 | |
| 2.08 | 2.35 | 2.10 | 2.37 | -18.48 | 21.08 | -59.19 | 110.80 | 0.8734 | 238.0 | 104.7 | |
| 0.00 | 1.08 | 0.00 | 1.23 | -19.69 | 17.51 | -62.76 | 111.53 | 0.9017 | -448.0 | -405.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
