SDO HMI 2011-05-30 21:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 22.93 | 98.38 | 14.95 | 64.44 | 15.70 | 40.26 | -37.79 | 64.41 | 0.6557 | -364.1 | -157.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-30 21:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.72 | 0.00 | 1.08 | 19.18 | 44.68 | -33.37 | 56.76 | 0.6234 | 520.0 | 403.9 | |
| 20.31 | 70.87 | 13.10 | 45.68 | 15.41 | 41.30 | -36.75 | 64.33 | 0.6423 | -1028.8 | -325.6 | |
| 0.00 | 1.44 | 0.00 | 0.96 | 18.29 | 40.27 | -37.78 | 60.80 | 0.6687 | 702.0 | 518.2 | |
| 0.00 | 0.72 | 0.00 | 0.47 | 15.67 | 40.45 | -37.60 | 64.39 | 0.6538 | -469.0 | -456.4 | |
| 0.00 | 3.97 | 0.00 | 2.59 | 15.45 | 40.37 | -37.68 | 64.75 | 0.6536 | -710.0 | -502.2 | |
| 0.00 | 2.80 | 0.00 | 1.83 | 15.20 | 39.99 | -38.06 | 65.30 | 0.6571 | -538.0 | -515.8 | |
| 0.00 | 0.81 | 0.00 | 0.54 | 16.60 | 39.22 | -38.83 | 63.70 | 0.6725 | -492.0 | -427.0 | |
| 0.00 | 1.17 | 0.00 | 0.79 | 15.37 | 38.53 | -39.52 | 65.76 | 0.6752 | 735.0 | 600.1 | |
| 0.00 | 0.81 | 0.00 | 0.57 | 17.24 | 36.69 | -41.36 | 64.05 | 0.7042 | 656.0 | 554.4 | |
| 0.00 | 1.17 | 0.00 | 0.81 | 15.81 | 36.55 | -41.50 | 66.05 | 0.6999 | 743.0 | 728.2 | |
| 0.00 | 1.53 | 0.00 | 1.08 | 16.80 | 36.04 | -42.01 | 64.93 | 0.7096 | 566.0 | 459.6 | |
| 0.00 | 0.99 | 0.00 | 0.69 | 15.62 | 36.22 | -41.83 | 66.44 | 0.7030 | 578.0 | 477.0 | |
| 0.00 | 1.08 | 0.00 | 0.75 | 15.81 | 36.09 | -41.96 | 66.24 | 0.7052 | 517.0 | 425.2 | |
| 2.62 | 8.04 | 1.85 | 5.66 | 16.71 | 35.50 | -42.55 | 65.29 | 0.7153 | 554.1 | 634.8 | |
| 0.00 | 1.26 | 0.00 | 0.94 | 15.85 | 32.24 | -45.81 | 67.67 | 0.7479 | -533.0 | -412.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
