SDO HMI 2011-05-31 04:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 32.43 | 180.77 | 27.94 | 157.07 | 16.63 | 21.12 | -53.07 | 68.97 | 0.8222 | -601.7 | -195.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-31 04:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.72 | 0.00 | 0.59 | 18.15 | 24.34 | -49.85 | 66.21 | 0.7960 | -564.0 | -454.2 | |
| 0.00 | 5.24 | 0.00 | 4.52 | 17.23 | 21.53 | -52.66 | 68.16 | 0.8202 | -438.0 | -323.4 | |
| 31.26 | 163.16 | 26.76 | 140.10 | 16.52 | 21.60 | -52.59 | 68.98 | 0.8179 | -853.4 | -227.2 | |
| 1.17 | 1.63 | 1.18 | 1.64 | 19.07 | 15.87 | -58.32 | 67.47 | 0.8727 | 561.2 | 537.2 | |
| 0.00 | 0.90 | 0.00 | 0.88 | 17.19 | 16.61 | -57.58 | 69.42 | 0.8634 | 365.0 | 322.1 | |
| 0.00 | 1.08 | 0.00 | 1.14 | 19.35 | 14.38 | -59.81 | 67.49 | 0.8847 | 427.0 | 361.6 | |
| 0.00 | 2.35 | 0.00 | 2.38 | 17.34 | 15.26 | -58.93 | 69.55 | 0.8746 | 535.0 | 486.9 | |
| 0.00 | 2.35 | 0.00 | 2.42 | 17.79 | 14.83 | -59.36 | 69.13 | 0.8787 | 493.0 | 411.7 | |
| 0.00 | 0.81 | 0.00 | 0.83 | 17.41 | 14.91 | -59.28 | 69.54 | 0.8775 | 265.0 | 241.2 | |
| 0.00 | 2.53 | 0.00 | 2.57 | 16.23 | 15.01 | -59.17 | 70.85 | 0.8748 | -535.0 | -415.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
