SDO HMI 2011-05-31 04:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 22.85 | 93.06 | 14.23 | 57.70 | 15.79 | 40.79 | -33.40 | 61.79 | 0.6028 | -375.4 | -268.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-31 04:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.99 | 0.00 | 1.18 | 19.13 | 46.90 | -27.29 | 51.91 | 0.5524 | 599.0 | 523.4 | |
| 14.64 | 67.40 | 8.96 | 41.27 | 15.62 | 41.76 | -32.43 | 61.49 | 0.5900 | -1140.1 | -452.7 | |
| 0.36 | 2.08 | 0.22 | 1.29 | 15.44 | 40.51 | -33.68 | 62.57 | 0.6045 | -806.8 | -550.1 | |
| 3.07 | 5.06 | 1.90 | 3.14 | 15.15 | 40.48 | -33.71 | 63.02 | 0.6033 | -792.0 | -536.2 | |
| 0.00 | 0.81 | 0.00 | 0.51 | 16.46 | 39.62 | -34.57 | 61.58 | 0.6210 | -678.0 | -559.6 | |
| 0.00 | 0.99 | 0.00 | 0.64 | 16.73 | 38.39 | -35.79 | 61.93 | 0.6371 | 584.0 | 490.0 | |
| 0.00 | 1.81 | 0.00 | 1.14 | 15.04 | 38.62 | -35.57 | 64.28 | 0.6257 | 693.0 | 516.5 | |
| 1.26 | 1.72 | 0.80 | 1.09 | 15.36 | 38.48 | -35.70 | 63.89 | 0.6290 | 738.1 | 603.0 | |
| 0.00 | 0.90 | 0.00 | 0.59 | 16.23 | 36.48 | -37.71 | 63.70 | 0.6573 | 634.0 | 465.6 | |
| 0.00 | 2.08 | 0.00 | 1.36 | 15.89 | 36.20 | -37.99 | 64.34 | 0.6591 | 833.0 | 656.3 | |
| 3.52 | 8.22 | 2.35 | 5.49 | 16.82 | 35.33 | -38.86 | 63.47 | 0.6735 | 629.3 | 514.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
