SDO HMI 2011-05-31 16:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 41.90 | 237.45 | 32.11 | 183.18 | 16.92 | 20.19 | -47.40 | 66.93 | 0.7668 | -479.7 | -142.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-05-31 16:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.90 | 0.00 | 1.46 | 21.60 | 21.98 | -45.61 | 60.44 | 0.7661 | -465.0 | -407.4 | |
| 0.00 | 0.99 | 0.00 | 0.73 | 17.73 | 23.37 | -44.22 | 64.73 | 0.7369 | -659.0 | -576.2 | |
| 0.00 | 1.35 | 0.00 | 0.99 | 17.57 | 23.20 | -44.39 | 65.01 | 0.7381 | -657.0 | -514.5 | |
| 0.00 | 1.26 | 0.00 | 0.93 | 17.57 | 23.02 | -44.57 | 65.08 | 0.7401 | -665.0 | -575.4 | |
| 0.00 | 1.26 | 0.00 | 0.93 | 17.41 | 23.02 | -44.57 | 65.28 | 0.7394 | -602.0 | -460.4 | |
| 0.00 | 2.26 | 0.00 | 1.72 | 20.39 | 21.90 | -45.69 | 61.97 | 0.7622 | -636.0 | -452.5 | |
| 0.00 | 1.72 | 0.00 | 1.32 | 21.18 | 21.54 | -46.05 | 61.15 | 0.7687 | -491.0 | -378.8 | |
| 0.00 | 2.62 | 0.00 | 1.98 | 17.27 | 21.29 | -46.30 | 66.12 | 0.7573 | -439.0 | -314.5 | |
| 35.67 | 175.71 | 26.73 | 131.81 | 16.41 | 21.47 | -46.12 | 67.16 | 0.7525 | -908.4 | -291.1 | |
| 0.00 | 1.17 | 0.00 | 0.89 | 17.18 | 20.95 | -46.64 | 66.36 | 0.7605 | -273.0 | -176.6 | |
| 0.00 | 1.26 | 0.00 | 0.97 | 17.24 | 20.70 | -46.90 | 66.37 | 0.7634 | 240.0 | 178.9 | |
| 0.00 | 0.54 | 0.00 | 0.42 | 18.31 | 20.23 | -47.36 | 65.21 | 0.7716 | -394.0 | -348.5 | |
| 0.00 | 1.17 | 0.00 | 0.92 | 18.92 | 19.72 | -47.88 | 64.63 | 0.7788 | -451.0 | -365.2 | |
| 0.00 | 2.44 | 0.00 | 1.91 | 17.39 | 19.37 | -48.23 | 66.65 | 0.7774 | 264.0 | 323.9 | |
| 0.00 | 10.11 | 0.00 | 8.63 | 19.07 | 15.80 | -51.79 | 65.76 | 0.8167 | 676.0 | 603.8 | |
| 0.00 | 0.81 | 0.00 | 0.68 | 17.32 | 16.52 | -51.07 | 67.63 | 0.8053 | 487.0 | 477.0 | |
| 0.00 | 1.63 | 0.00 | 1.41 | 19.27 | 15.18 | -52.41 | 65.71 | 0.8228 | 479.0 | 481.6 | |
| 0.00 | 1.44 | 0.00 | 1.28 | 19.54 | 14.36 | -53.23 | 65.64 | 0.8309 | 364.0 | 200.8 | |
| 0.00 | 2.26 | 0.00 | 1.93 | 17.18 | 15.29 | -52.30 | 68.15 | 0.8166 | 656.0 | 539.4 | |
| 0.00 | 0.81 | 0.00 | 0.72 | 19.28 | 14.21 | -53.38 | 65.98 | 0.8316 | 224.0 | 174.8 | |
| 2.62 | 17.79 | 2.27 | 15.58 | 17.79 | 14.77 | -52.82 | 67.57 | 0.8229 | 666.0 | 514.3 | |
| 0.00 | 1.08 | 0.00 | 0.91 | 15.93 | 15.51 | -52.08 | 69.59 | 0.8116 | -558.0 | -515.7 | |
| 1.35 | -21.00 | 1.19 | -21.00 | 18.21 | 14.32 | -53.27 | 67.20 | 0.8280 | 769.1 | 999999 | |
| 2.26 | 3.88 | 1.92 | 3.30 | 15.94 | 15.14 | -52.45 | 69.68 | 0.8151 | -593.1 | -429.8 | |
| 0.00 | 1.99 | 0.00 | 1.76 | 18.64 | 13.97 | -53.63 | 66.80 | 0.8322 | 418.0 | 289.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
